Digital Watchdog - DWC-MB75Wi4TWDMP - 5MP MEGApix Weather Resistant Bullet, 4mm Lens

Product Overview

The Digital Watchdog DWC-MB75Wi4TWDMP is a 5MP MEGApix weather-resistant bullet camera equipped with a 1/2.8" CMOS sensor and a 4.0mm fixed lens that delivers an 82.3° horizontal field of view.

Key Configuration

• • Image sensor: 4MP 1/2.8" CMOS; maximum resolution: 5MP (2560×1920)
• • Lens: 4.0mm fixed lens; horizontal FOV: 82.3°, vertical FOV: 58.8°
• • IR distance: Smart IR up to 100 ft (30.5 m); minimum illumination: 0.16 lux color, 0.0 lux B/W
• • Video compression: H.264, H.265
• • Power: PoE (Class 2) or DC12V (adapter not included)

Key Features

Featuring Star-Light Plus™ color technology for ultra-low light, this camera utilizes a mechanical IR cut filter and Smart IR™ LEDs to maintain visibility while preventing overexposure. Video processing is optimized using Smart DNR™ 3D digital noise reduction, Auto Gain Control (AGC), and Auto White Balance (AWB). The unit supports internal motion detection, image mirror/flip settings, and is engineered for native integration with DMP video management software.

Technical Context

ONVIF compliant and optimized for DMP video management software, this camera features a white, die-cast aluminum housing with an IP67 rating for full dust-tight protection and water resistance up to 3 feet. The hardware is UL-listed, fully NDAA-compliant, and backed by a 5-year warranty. For power and signal installation, #18 AWG cabling is recommended.

Installation Notes

This camera operates within a temperature range of -22°F to 122°F (-30°C to 50°C), requiring a startup temperature of at least -4°F (-20°C). Power is supplied via PoE Class 2 or 12V DC, with power adapters and mounting accessories sold separately. Constructed as a compact cylinder, the camera body measures 2.65” (67.5 mm) in diameter by 6.41” (163 mm) in length, weighing 1.01 lbs (0.46 kg).
