ExacqVision - IFS02-D12-OIB4 - 2MP Illustra Flex Gen4 Minidome AI Camera, 2.7-13.5mm
Product Overview
The Exacq IFS02-D12-OIB4 is a 2MP Illustra Flex Gen4 minidome featuring a 2.7-13.5mm motorized P-iris lens and a Sony CMOS sensor, delivering up to 60 fps. It includes the Flex AI suite for person and vehicle classification, alongside 141 dB True WDR, 50m Smart IR, and gyro-based EIS. Built for harsh environments, it carries IP67, NEMA 4X, and IK10 ratings and supports two-way audio and 1TB edge storage.
Key Configuration
- • Imager: 2MP Sony 1/2.8" progressive scan CMOS; max frame rate: 60/50 fps
- • Lens: 2.7–13.5mm motorized varifocal, P-Iris, F1.6–F3.1; one-touch autofocus; 98.47°–31.1° horizontal FOV
- • IR Illuminator: 850 nm Smart/Adaptive IR up to 50m (164 ft); min. illumination: 0.05 lux (Color), 0.005 lux (B/W)
- • Power: PoE 802.3af (Class 3) or 24VAC; max consumption: 10.0W (PoE) / 10.3W (24VAC)
- • Dimensions: Ø145 × 106.5 mm; net weight: 1.01 kg (2.23 lbs)
Key Features
It features the Flex AI suite for pre-calibrated object classification (people/vehicles) and advanced analytics like perimeter and dwell detection. It utilizes gyro-based EIS and 141 dB True WDR for stable, high-contrast imaging. Key features include Corridor Mode, encrypted 1TB edge storage with TrickleStor offline recording, and bi-directional audio. The unit is built for reliability with power failover support and JCI cyber norm compliance.
Technical Context
Designed for extreme environments, this unit operates from -50°C to +60°C with a -40°C cold-start capability and up to 95% humidity resistance. It offers flexible 3-axis mechanical adjustment (350° pan, 67° tilt, 355° rotation) and supports a wide array of network protocols, including IPv6, TLS, and SSH. The camera is ONVIF Profiles S, G, T, and M conformant and features optional Wi-Fi connectivity via a USB dongle. Finished in Signal White (RAL 9003), it ensures seamless integration and high-standard compatibility for enterprise security systems.
Installation Notes
The unit is engineered for maximum durability with IP66, IP67, NEMA 4X, and IK10 ratings, ensuring protection against weather and vandalism. It supports flexible power options via PoE 802.3af (Class 3) or 24VAC and includes a Micro USB port for an optional Wi-Fi dongle to simplify installation. Additionally, it supports corridor mode for vertical field-of-view optimization and comes backed by a 5-year warranty.
| Camera Features | Flex Gen4 Outdoor Mini Dome Camera |
| AI Object Classification | Classes: Person, Bicycle, Bus, Car, Motorbike, Train, Truck, Any Class Sub-Classes (attributes): Person Clothing Color (Upper, Lower), Vehicle Color Rules: Object Detected, Perimeter, Linger, Dwell, Abandoned/Removed, Enter, Exit, Crowd, Queue, Direction |
| Audio | Bi-directional, 1x Line input and 1x Line output |
| Alarm Input/Output | 1x Alarm In and 1x Alarm Out |
| Day/Night | True Day/Night CF removal |
| Defog | Supported |
| Dimensions | Ø145x106.5mm (Ø5.71 x 4.19 in) (without mount plate) Ø145.3x113.5mm (Ø5.72 x 4.47 in) (with mount plate) |
| Dynamic Range | True multi shutter WDR up to 141 dB Off, TWDR, TWDR 3x, SmartWDR |
| Environment Rating | IEC 60529 IP66, IEC 60529 IP67 IEC 62262 IK10 BS EN IEC 63000 ROHS, REACH, WEEE NEMA 250 Type 4x |
| Ethernet | IEEE 802.3, 10/100Base-T Ethernet, RJ45, auto sensing |
| Field of View | 2MP: H: 98.47°(W) – 31.1°(T) V: 51.88°(W) – 17.55°(T) 5MP: H: 97.57°(W) – 31.74°(T) V: 70.26°(W) – 23.84°(T) 8MP: H: 112.1°(W) – 47.5°(T) V: 58.0°(W) – 26.6°(T) |
| H.264 | yes |
| H.265 | yes |
| Housing Color | Signal White Pantone RAL 9003 |
| Imager | 2MP: Sony 1/2.8” Progressive Scan CMOS imager 5MP: Sony 1/2.8” Progressive Scan CMOS imager 8MP: Sony 1/1.8” Progressive Scan CMOS imager |
| Image Stabilization | Electronic image stabilization (EIS) using gyro sensor (coming soon) |
| IR Illuminator | 850 nm, Smart / Adaptive IR, up to 50m (164 ft) |
| Lens Type | 2MP: 2.7 mm – 13.5 mm, MFZ, P-Iris, F1.6(W) – F3.1(T) 5MP: 2.7 mm – 13.5 mm, MFZ, P-Iris , F1.31(W) – F2.37(T) 8MP: 3.6 – 11mm, MFZ, P-iris, F1.3(W) – F2.15(T) One touch auto focus, manual, and automatic focus with zoom |
| Max Frame Rate | 2MP: 60/50 fps 5MP: 30/25 fps 8MP: 15/12.5 fps |
| Minimum Illumination | 2MP: Color: 0.05 lux, B/W: 0.005 lux 5/8MP: Color: 0.1 lux B/W: 0.01 lux |
| MJPEG | yes |
| Motion Detection | 3 zones supported |
| Onboard Storage | microSDXC slot, Class 10 or better, up to 1TB supported (Card not included) Pre event / Post event 1- 10 sec Encrypted storage and streaming TrickleStor offline recording and backfilling |
| Operating Temperature | -50°C (-58°F) to +60° C (140°F) (IR off at +50° C/122° F) Start-up temperature: -40°C (-40°F) Humidity up to 95% RH, Non-Condensing |
| Pan Travel | Pan 350°, Tilt 67°, Rotation 355° |
| Power Draw | 2MP PoE Typ. 0.1A / Max 0.21A Typ. 4.5W / Max 10.0W 24VAC Typ. 0.38A / Max 0.75A Typ. 4.7W / Max 10.3W 5MP PoE Typ. 0.11A / Max 0.22A Typ. 5.2W / Max 10.4W 24VAC Typ. 0.43A / Max 0.78A Typ. 5.4W / Max 10.7W 8MP PoE Typ. 0.12A / Max 0.25A Typ. 5.5W / Max 12.0W 24VAC Typ. 0.45A / Max 0.88A Typ. 5.7W / Max 12.3W |
| Power Input | PoE 802.3af (802.3at Type 1) Class 3 | 24VAC |
| Privacy Zones | 10 user definable rectangular zones |
| Resolution Options | 2MP: 16:9: 1920 x 1080 (2MP) to 480x272 5MP: 4:3: 2560 x 1920 (5MP) to 480x272 8MP: 16:9: 3840 x 2160 (8MP) to 480x272 |
| Simultaneous Users | 10 users |
| Supported Protocols | TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WS-Addressing, CIFS, UPNP, LLDP, SIP, ARP, EAP-LEAP, QoS |
| Video Streams | Triple Streaming with a maximum of 5 concurrent shared streams |
| Weight | Net 1.01 kg (2.23 lbs.), Gross 1.29 kg (2.84 lbs.) |
| Wi-Fi | Micro USB via optional USB Wi-Fi Dongle IA-KIT-WD-UUA |
