ExacqVision - IP08-96T-R2XW - IP 2U Rackmount Redundant X-Series NVR with 8 IP Professional Licenses, 96TB

Product Overview

The Exacq IP08-96T-R2XW is a 2U redundant X-Series NVR featuring 96TB RAID6 storage, 72TB usable and dual 480GB SSDs in RAID1 for Windows Server 2022. It includes 8 IP Professional licenses and high-performance hardware, including 32GB RAM, redundant power supplies, and dual 10GbE NICs. For management and reliability, the unit features iDRAC9 Enterprise and is backed by a 5-year SSA and a 5-year next business day on-site hardware warranty.

Key Configuration

• • Storage: 96TB RAID6 (72TB usable); 12 hot-swappable bays (max 240TB)
• • Operating system: Windows Server 2022 on dual 480GB SSD RAID1; CPU: Xeon Silver 4310 (12 cores/24 threads); RAM: 2×16GB (32GB)
• • Video throughput: 950 Mbps (Linux); maximum IP streams: up to 175
• • Network interfaces: 2× 1GbE onboard + 2× 10GbE NIC
• • Dimensions: 18.97"W × 3.41"H × 27.85"D (482 × 86.8 × 707.78 mm); weight: 78 lbs (35.45 kg)

Key Features

The Exacq X-Series NVR supports up to 950 Mbps of throughput, 175 cameras, and 500 remote clients. Maximum uptime is ensured via redundant power, RAID6 storage, and RAID1 OS SSDs, complemented by ESM Failover and hardware health monitoring. Pre-loaded with exacqVision Professional, the system features EasyConnect discovery, two-way audio, and advanced forensic search. It is also capable of hosting Certified Software Applications (CSAs) for analytics and POS integration.

Technical Context

Supporting H.265, H.264, and MJPEG, this 2U rackmount NVR delivers high-performance throughput up to 950 Mbps. It features iDRAC9 Enterprise for advanced remote management and provides extensive connectivity via USB 3.0, VGA, and serial ports. Designed for mission-critical reliability, the system includes six fully redundant cooling fans and 800W Platinum redundant hot-swap power supplies compatible with AC or DC environments.

Installation Notes

The 2U rackmount unit measures 18.97" × 3.41" × 27.85" and weighs 78 lbs, with a sliding rail kit included for easy installation.
