GeoVision - VR-GERM064-0000 - Software License Software 64ch (Windows version)

Product Overview

The GeoVision VR-GERM064-0000 is a 64-channel Windows license for GV-ERM, centralizing the management of remote GV-IP and Target cameras. It provides a single interface for live viewing, NAS recording, and video playback without needing to visit individual host web pages. The system supports 32 channels for free and scales to 64 channels with this license and a GV-USB dongle. It also enables direct storage monitoring and remote recording control for streamlined operation.

Key Configuration

• • Maximum channels: 32 free, 64 with GV-USB dongle
• • Supported hosts: GV-System (DVR/NVR), GV-VMS, GV-Recording Server, GV-IP Camera, GV-Target Camera, GV-SD220/220-S, GV-Video Server, GV-SNVR0400F/1600 (up to 64 hosts)
• • Window divisions: 4,6,8,9,10,13,16,25,36,49,64
• • Display modes: fisheye dewarping, PIP, PAP, wide-angle lens dewarping, fisheye object tracking, zoom, snapshot
• • Supported languages: 30+, including English, French, German, Spanish, Russian, Chinese, Japanese, Arabic

Key Features

The software features dual-channel display, manual snapshots, and PTZ control. It supports NAS storage assignment for GV-IP devices (V3.0+) and allows for remote recording management and two-way audio. Administrative tools include batch IP assignment, storage monitoring, and remote playback (1 window). Status indicators use yellow, green, and red colors for monitoring states, while playback modes offer fisheye dewarping, PIP/PAP, and defogging.

Technical Context

GV-Target Cameras require firmware V1.02 or later, while GV-IP Cameras must be V3.0 or later for NAS setup. The GV-NAS System is a Linux-based storage solution specifically designed for recordings from these devices. The system supports time synchronization with GV-Edge Recording Manager to ensure consistent logging across all GV-IP devices.

Installation Notes

Expanding to 64 channels requires a GV-USB dongle and is exclusive to the Windows version. The software enables host batch management, allowing for rapid IP address configuration and time synchronization across multiple units. Additionally, it streamlines large-scale deployments by supporting centralized NAS setup for all connected GV-IP devices.
