Hanwha - ARN-410S-2TB - 4 Channel Network Video Record PoE Wisenet A-Series, 2TB

Product Overview

The Hanwha XRN-1620SB1 is an 8K Intel-based NVR with 16 channels and 16 built-in PoE/PoE+ ports (200W PoE budget). It supports up to 32MP camera resolution and uses H.265/H.264/MJPEG compression for efficient recording and storage. It includes 4 internal SATA HDD bays supporting up to 6TB per drive (24TB total maximum, HDDs not included).

Key Configuration

• • Channels: up to 16 IP camera inputs; PoE ports: 16 × RJ45 (10/100 Mbps), 200W total PoE budget
• • HDD bays: 4 × fixed internal SATA, up to 6TB per HDD (max 24TB total); no HDD included
• • Recording bandwidth: 140 Mbps; playback bandwidth: 32 Mbps
• • Video outputs: HDMI (4K/3840×2160 @30Hz) and VGA (1920×1080 @60Hz) dual monitor
• • Dimensions: 440 × 89.8 × 428.4 mm (17.32" × 3.54" × 16.87"); weight: 5.76 kg (12.70 lb)

Key Features

Supports high-performance decoding up to 32MP at 15 fps (H.265) with multiple display modes including FHD clone, UHD single, and FHD expand for flexible monitoring layouts. It supports up to 64-channel simultaneous playback, advanced recording modes (normal, event, schedule, dual stream), and comprehensive event handling such as motion, video loss, analytics, audio, and user events with actions like alerts, PTZ control, FTP backup, and system shutdown. Additional features include fisheye dewarping via CMS, 16-channel audio with two-way communication, alarm I/O, dual Gigabit LAN plus 16 PoE ports, ARB and Failover support, plugin-free web interface, and P2P QR code mobile setup.

Technical Context

Runs on embedded Linux with support for IPv4/IPv6, RTSP, HTTPS, ONVIF Profile-S, SUNAPI, SNMP, and standard networking protocols such as DNS, DDNS, and uPnP. Security features include IP filtering, 802.1X authentication, encrypted communications, device certificates (Hanwha Techwin Root CA), access logging, and signed firmware for system integrity. Web viewing is supported on Windows 10 and macOS 10.13 via Chrome, Edge, and Safari. The system uses 100–240V AC power input with up to 310W total consumption (including PoE), with a 200W PoE budget, housed in a black metal chassis.

Installation Notes

16-channel black metal NVR measuring 440 × 89.8 × 428.4 mm and weighing 5.76 kg, operating at 0°C to 40°C with 20–85% humidity range. It includes 16 PoE/PoE+ ports (200W total budget), 4 internal SATA HDD bays supporting up to 6TB each, and HDMI + VGA outputs for dual display monitoring. Additional features include ARB and Failover (N+1) reliability, plugin-free web UI 2.0, P2P QR mobile setup, and AI search support when used with compatible Wisenet AI cameras.
