Hanwha - PNO-A9311RLP - 4K Low- Moderate Speed Dedicated LPR Bullet Camera with Wisenet Road AI
Product Overview
The Hanwha PNO-A9311RLP is a 4K dedicated LPR bullet camera optimized for low- to moderate-speed traffic applications. Driven by an embedded Wisenet Road AI analytics suite, it utilizes a 1/1.8" CMOS sensor paired with a 6.91–214.7mm (31x) motorized varifocal lens F1.36–F4.6, 60.92°–2.2° HFOV. The camera captures 4K resolution (3840×2160) at up to 30 fps, employing H.265, H.264, and MJPEG compression codecs alongside WiseStreamⅡ and WiseStreamⅢ bandwidth-optimization technologies.
Key Configuration
- • Imaging device: 1/1.8" CMOS; resolution: 3840×2160 (4K) at up to 30 fps (H.265/H.264)
- • Lens: 6.91~214.7mm motorized varifocal (31x zoom), P-iris, F1.36(W)–F4.6(T); horizontal FOV: 60.92°(W)–2.2°(T)
- • IR viewable length: WiseIR up to 70m (230 ft) for general IR, LPR plate reads approx. 200 ft (61m)
- • Minimum illumination: color 0.075 lux, B/W 0.0075 lux, 0 lux with IR
- • Power: PoE+ (IEEE 802.3at, Class 4) or 12V DC; PoE+ max 25.5W / typical 14.0W
Key Features
It recognizes 70+ vehicle makes, 600+ models, and 11 colors within an 18 m-75 m (60–250 ft) forward range. Image optimization is driven by 120dB WDR, SSNRⅤ noise reduction, and gyro-based Digital Image Stabilization. Built-in security includes TPM 2.0 (FIPS 140-2 level 2) alongside 4096 MB of RAM and 1024 MB of Flash memory.
Technical Context
Featuring a 3m minimum object distance, simple focus, and a 1/5 to 1/12,000 sec electronic shutter, this camera supports up to 6 streaming profiles over standard protocols like HTTPS and MQTT. Its robust security includes 802.1X authentication, secure boot, firmware forgery validation, and an onboard TPM module with FIPS 140-2 level 2 compliance. Built for harsh deployments, the white aluminum enclosure features a hard-coated window, carries IP66/IP67, IK10, and NEMA4X ratings, and installs easily via a 3/4" M25 conduit hole or standard single, double, octagon, and square gang boxes.
Installation Notes
Measuring Ø136.2 × 358.7 mm (Ø5.36" × 14.12") and weighing 3200g (7.05 lb), this camera operates from -40°C to +55°C (-40°F to 131°F) with a pre-installed Road AI application and a hard-coated window. It is powered via standard PoE+ or 12V DC, eliminating the need for a high-power HPoE injector, and includes dual CVBS and USB installation video outputs alongside a microSD edge storage slot with a 32GB card pre-installed.
| Video | |
| Imaging Device | 1 /1.8" CMOS |
| Resolution | 3840x2160 , 3072x1728, 2592x1944, 2688x1520, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720 , 1024x768, 800 x 600, 800 x 448, 720 x 576, 720x480, 640x480, 640x360 |
| Max. Framerate | H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps |
| Min. Illumination | Color: 0.075Lux(F1.36, 1/30sec, 30IRE) BW: 0.0075Lux(F1.36, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
| Lens | |
| Focal Length (Zoom Ratio) | 6.91~214.7 mm (31x) motorized varifocal |
| Max. Aperture Ratio | F1.36(Wide)~F4.6(Tele) |
| Angular Field of View | H: 60.92°(Wide)~2.2°(Tele) V:35.26°(Wide)~1.24°(Tele) D:69.18°(Wide)~2.52°(Tele) |
| Min. Object Distance | 3 m(9.84ft ) |
| Focus Control | Simple focus |
| Lens Type | P iris |
| Operational | |
| Camera Title | Displayed up to 85 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, WDR, SSDR |
| Wide Dynamic Range | 120 dB |
| Digital Noise Reduction | SSNRⅤ |
| Digital Image Stabilization | Support(built-in gyro sensor) |
| Motion Detection | 8 ea, polygonal zones |
| Privacy Masking | 3 ea, rectangle zones - Color: Gray/Black/White |
| Gain Control | Low / Middle / High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation | Flip, Mirror, Hallway view(90/270) |
| Analytics | Defocus/ Motion/ Tampering/ Audio/ Shock detection, Sound classification |
| Alarm I/O | 2 configurable I/O ports, DC 12V output(Max. 50mA ) |
| Alarm Triggers | Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
| Alarm Events |
|
| Audio In | Selectable(mic in/line in) |
| Audio Out | Line out |
| Light Type | IR LED (850nm) |
| IR Viewable Length | WiseIR 70m(229.66ft) |
| Network | |
| Ethernet | Metal shielded RJ-45(10/100/1000 BASE-T) |
| Video Compression | H.265/H.264: Main/High, MJPEG |
| Audio Compression | G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
| Smart Codec | Manual(5ea area), WiseStreamⅡ |
| Bitrate Control | H.264/H.265: CBR or VBR MJPEG: VBR |
| Streaming | Unicast(6 users) / Multicast Multiple streaming(Up to 6 profiles) |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), MQTT |
| Security | HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1 X Authentication(EAP-TLS, EAP-LEAP ) Device Certificate(Hanwha Techwin Root CA) TPM 2.0 with FIPS 140-2 level2 Secure boot, Verify firmware forgery |
| Application Programming Interface | ONVIF Profile S/G/T/M SUNAPI(HTTP API) |
| Security | |
| OS / Firmware Protect | Encrypted Firmware, Secure boot, Signed Firmware |
| User authentication | Digest Authenticaton, Prevent brute-force attack |
| Network authentication | IEEE 802.1X (EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication | HTTPS, WSS (WebSocket Secure) |
| Access Control | IP-based access control |
| Data Protect | Encryption Credentials, Encrypt compress for live recording file |
| Audit | Access / System / Event Log management |
| Device ID | Device certificate (Hanwha Techwin Root CA) |
| Secure Storage | TPM, SDcard partition encrypt |
| Security Certificate | TPM with FIPS 140-2 level 2 |
| General | |
| Webpage Language | English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage | Micro SD/SDHC/SDXC 1slot (32GB Card preinstalled) |
| Memory | 4096 MB RAM, 1024MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity | -40 °C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -30°C |
| Storage Temperature / Humidity | -50 °C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| EPA(Effective Projected Area) | 0.039 m 2 |
| Certification | IP66/IP67, IK10, NEMA4X |
| Input Voltage | PoE+(IEEE802.3at, Class4), 12VDC |
| Power Consumption | PoE+: Max 25.5W, typical 14.0W 12 VDC: Max 24.0W, typical 12.7.W |
| Mechanical | |
| Color / Material | White / Aluminum Hard-coated window |
| RAL Code | RAL9003 |
| Product Dimensions / Weight | ø136.2x358.7mm(ø5.36x14.12")(Without sunshield), 3200g(7.05lb) * backbox: ø160mm(ø6.30") |
| Compatible Conduit hole / Gangbox | 19.1 mm(3/4" )(M25) single, double, 4" octagon, 4" square |
| Certifications & Standards |
| EMC | FCC 47 CFR 15 Subpart B Class A ICES-3(A)/NMB-3(A) CE/UKCA - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3 VCCI CISPR 32 Class A RCM AS/NZS CISPR 32 Class A |
| Safety UL 62368-1, CAN/CSA C22.2 NO. 62368-1 | IEC/EN 62471 |
| Environment | IEC/EN 63000 IEC/EN 60529 IP66/67, IEC/EN 62262 IK10 |
| DORI (EN62676-4 standard) | |
| Detect (25PPM/ 8PPF) | Wide: 130.6m(428.4ft) / Tele: 4,000m(13,122ft) |
| Observe (63PPM/ 19PPF) | Wide: 52.2m(171.4ft) / Tele: 1600m(5,249ft) |
| Recognize (125PPM/ 38PPF) | Wide: 26.1m(85.7ft) / Tele: 800m(2,625ft) |
| Identify (250PPM/ 76PPF) | Wide: 13.1m(42.8ft) / Tele: 400m(1,312ft) |
| Wisenet Road AI LPR/ANPR/MMCR | |
| Solution | City Traffic |
| Speed Description | High Speed |
| Lane Coverage | Up to 2 lanes (5m/18ft Wide) |
| Speed limit | Up to 100kmh (65mph) |
| Min. Forward Distance | 18 m (60ft ) |
| Max. Forward Distance | 75 m (250ft ) |
| Max. Horizontal Angle | 25 ° |
| Max. Vertical Angle | 25 ° |
| Horizontal Offset | Up to 12m (24ft) |
| Camera Height | Up to 12m (24ft) |
| Vehicle Recognition | Make : 70+ Makes Model : 600+ models Color : 11 colors |
