Hanwha - WRR-P-S206S1-280TB - 2U Wisenet WAVE Network Video Recorder with 4 Professional Wisenet WAVE Licenses, 280TB Raw
Product Overview
The Hanwha WRR-P-S206S1-280TB is a 2U Wisenet WAVE NVR with 4 Professional licenses pre-installed, supporting up to 470 Mbps recording bandwidth. It features 28 hot-swappable HDD bays with 280TB raw storage (218TB usable RAID 6), dual Intel Xeon Gold processors, 64GB DDR5 RAM, dual 480GB SSD OS drives, RAID 0/1/5/6 support, Nvidia A400 GPU, dual 1GbE and dual 10/25GbE networking, redundant 1400W power supplies, and Windows Server 2022 Standard.
Key Configuration
- • Recording bandwidth: up to 470 Mbps
- • Included licenses: 4 × Wisenet WAVE Professional licenses
- • Storage: 280TB raw (218TB usable after RAID 6), 28 × 3.5" front hot-swappable bays (up to 480TB raw)
- • OS drives: 2 × 480GB SSD (RAID 1, internally mounted)
- • Dimensions: 481.6 × 837 × 86.8 mm (18.96" × 32.95" × 3.41") and weight 46.3 kg (102.07 lb)
Key Features
It features dual Intel Xeon Gold 5416S CPUs, 64GB DDR5 RAM, Windows Server 2022 Standard, and RAID 0/1/5/6 support with 8GB NV cache. Includes an Nvidia A400 GPU, MiniDP/VGA outputs, dual 1GbE RJ45 and dual 10/25GbE SFP28 ports, IPMI remote management, redundant 1400W power supplies, USB 2.0/3.0 connectivity, and a serial port. The system also comes with a keyboard, mouse, sliding rail kit, and cable management arm, and is certified to UL, NOM, RoHS, TUV, and GS standards.
Technical Context
This 2U Wisenet WAVE NVR comes pre-installed with 4 Professional licenses and supports up to 470 Mbps recording bandwidth. It features 28 front hot-swappable HDD bays supporting up to 480TB raw storage, with RAID 6 providing 218TB usable capacity from 280TB raw. The system includes dual 10/25GbE SFP28 ports for high-speed networking, IPMI for remote server management, and redundant power supplies for high availability. A rail kit with cable management arm is also included for rack installation.
Installation Notes
Designed in a 2U rackmount form factor, the system measures 481.6 × 837 × 86.8 mm and weighs 46.3 kg fully loaded with drives. It operates in temperatures from 10°C to 30°C with 10–80% non-condensing humidity and supports storage temperatures from -40°C to 65°C. The unit supports 100–240 VAC power input and includes hot-swappable HDD bays for easy maintenance, an IPMI port for remote management, a rail kit with cable management arm, and an included keyboard and mouse.
| System | |
|---|---|
| Video Management Software | Wave VMS |
| Recording Bandwidth | Up to 470 Mbps * Bandwidth performance figures based on performance testing by Hanwha Vision using Wave VMS |
| Included Licenses | 4 x Wave Professional License |
| Storage | |
| OS Drive Bays | 2 x 480GB Dual RAID 1 SSD (Internally Mounted) |
| Data Drive Bays | 28 x 3.5" Front Hot Swappable Bays |
| Data Storage | Up to 480TB raw |
| Interface | |
| Network Interface | 2 x RJ45 1GbE + 2 x 10/25GbE SFP28 |
| Memory | 64GB DDR5 |
| USB Ports | 1 x USB 2.0 (Front), 1 x USB 2.0 + 1 x USB 3.0 (Rear) |
| Other Ports | Serial |
| Keyboard & Mouse | Included |
| Sliding Rail Kit | Included, with Cable Management Arm |
| Construction | |
| Dimensions (W x D x H) | 18.96" (481.6mm) x 32.95" (837mm) x 3.41" (86.8mm) |
| Weight | 102.07 lbs (46.3 kg) * Weight is on the chassis fully loaded with drives |
| Electrical | |
| Power Input | 100 - 240 VAC |
| Heat Dissipation | 3001 Max BTU/hr |
| Environmental | |
| Operating Temperature | 50°F - 86°F (10°C - 30°C) |
| Storage Temperature | -40°F to 149°F (-40°C to 65°C) |
| Operating Humidity | 10% to 80% RH non-condensing |
| Certifications and Compliance | |
| Certifications | UL, NOM, RoHS, TUV, GS |
