IDIS - AV02CMB-100 - 2MP Bullet-Style IP Camera with 3.6 mm Lens
Product Overview
The IDIS AV02CMB-100 is a 2MP (1080p) bullet-style IP camera delivering 1920x1080 resolution. This outdoor bullet camera features a fixed 3.6mm lens with 85° horizontal field of view, 120dB WDR, and 20m IR illumination. H.265/H.264/MJPEG compression with SNAPstream+ technology provides efficient bandwidth management, with ONVIF Profiles S and T compliance.
Key Configuration
• 2MP (1920×1080) resolution at up to 30 fps (single stream)
• Fixed 3.6 mm lens with F2.0 fixed iris, 85° (H) / 46° (V) field of view
• Power: PoE IEEE 802.3af Class 3, max consumption 6.6W
Key Features
Advanced features include motion detection, tampering alerts, unlimited privacy masking, CorridorView rotation modes, and electronic PTZ with forensic zoom. The camera supports two-way network protocols, secure HTTPS/SSL communication, and up to 10 users for live viewing/administration. It is IP66/IK10 rated and NDAA compliant.
Technical Context
SNAPstream+ dynamically optimizes compression based on scene complexity to reduce bandwidth and storage while preserving image quality. NightView enhances low-light visibility, and Smart IR automatically adjusts infrared intensity to prevent overexposure of nearby objects. CorridorView supports 90° image rotation for hallway installations, while Defog improves visibility in fog or haze. The 3-axis wall mount allows flexible positioning with 360° pan, 90° tilt, and 360° z-axis rotation.
Installation Notes
Bullet camera with die-cast aluminum housing and included 3-axis adjustable wall mount for flexible installation. It measures 71.5 × 86 × 172.8 mm and weighs 0.43 kg, operating from −20°C to +50°C with 0–90% non-condensing humidity and −40°C to +60°C storage range. The camera is powered only via PoE IEEE 802.3af Class 3, with no auxiliary power input or SD card storage support. It is IP66 weatherproof and IK10 impact resistant, finished in AV Costar White (Pantone Cool Gray 1C).
| Camera | |
|---|---|
| Image Sensor | 1080p (2.1MP) CMOS Progressive Sensor |
| Optical Format | 1/2.8" |
| Minimum Illumination (Color - Day Mode) | 0.05 Lux |
| Minimum Illumination (B/W - Night Mode) | 0.005 Lux |
| Full FOV Resolution | 1920 H x 1080 V |
| Scaling | Yes (See Scaling Resolutions Below) |
| IR Illumination | Yes |
| Dynamic Range | 120dB |
| Frame Rates (Single Stream) | Up to 30fps (1080p) |
| Frame Rates (Multi-Stream) | Up to 30fps (1080p) + 20fps (1080p) Up to 30fps (1080p) + 30fps (720p) + 30fps (VGA) |
| Lens | Fixed Iris 3.6mm, F2.0, H-FOV = 85°, V-FOV = 46° |
| Programmability | |
| Optics | Fixed lens |
| Low-Light Performance | NightView™ technology, Smart IR |
| Programmable Shutter Speed | Auto/manual 0.1ms ~ 500ms |
| Motion Detection | Real-time, 1024 detection zones |
| Privacy Masking | Unlimited |
| Backlight Compensation | Auto |
| White Balance Mode | Auto/manual |
| Gain Control | Auto |
| Flicker Control* | 5Hz–255Hz adjustable |
| Image Rotation | CorridorView™ (90°, 180°, and 270° image rotation) + mirror |
| Scaling Resolutions (1080p) | 1920x1080, 1280x720, 960x540, 640x480, 640x360, 320x240 |
| Wide Dynamic Range | Adjustment between WDR and LDR modes |
| Efficiency | SNAPstream+™ (Smart Noise Adaptation and Processing) Bit rate and bandwidth limitation control |
| Defog | Supported |
| Miscellaneous Controls | Programmable brightness, contrast, sharpness, saturation, hue Electronic pan, tilt, zoom (PTZ) |
| Password | 16-digit ASCII character password |
| On-Screen Display (OSD) | Time/date/camera name/custom text |
| Data | |
| Compression Type | H.265/H.264 (MPEG-4, Part 10)/Motion JPEG |
| Bit Rate Control | 64K–8000K |
| Smart Codec | Smart GOP/Smart ROI |
| Transmission Protocols | SNMP, HTTP, HTTPS, IPv6, IPv4, SSL, TCP/IP, UPnP, UDP, RTCP, RTSP, RTP, SMTP, NTP, DHCP, FTP, 802.1x, Zero Configure 10/100Base-T Ethernet network interface, RJ45 |
| Multi-Streaming | 2 x H.265/H.264 stream, 1 x M-JPEG stream |
| Users | Live viewing/Administrator for up to 10 clients |
| Event | |
| Event Trigger | Motion detection, tampering detection |
| Notifications | Send/record message via e-mail/FTP/NAS, record JPG/mp4 |
| Compliance & Listings | |
| Industry Standard | ONVIF Profile S and T conformant |
| FCC Compliance | 47 CFR 15 Class A |
| Environmental | RoHS, REACH, WEEE |
| Markings (CE) | EN55032 Class A, EN55024, EN61000-3-2, EN61000-3-3, EN60950 |
| Mechanical | IK-10 (EN62262), IP66 (EN60529) |
| Environmental | |
| Operating Temperature | -20°C (-4°F) to +50°C (122°F) |
| Humidity | 0% to 90% (non-condensing) |
| Storage Temperature | -40°C (-40°F) to +60°C (140°F) |
| Electrical | |
| Power Over Ethernet | PoE IEEE 802.3af, Class 3 Total PoE solution (no external power requirement) |
| Power Consumption | 6.6W PoE max (1080p) |
| IR Illuminator | |
| LEDs | 4pcs, Smart IR |
| Projection Distance | 66ft (20m) max |
| Mechanical | |
| Casing | Die-cast aluminum cylindrical (bullet-style) housing IP66 weather proof standard IK-10 impact-resistant |
| Mount | Easily adjustable 3-axis with 360° pan, 90° tilt and 360° z-axis |
| Unit Dimensions | 2.8" H (71.5mm) x 3.39" W (86mm) x 6.8" D (172.8mm) (See Dimensions) |
| Packaged Dimensions | 4.7" H (120mm) x 5.3" W (135mm) x 7.9" L (200mm) |
| Unit Weight | 0.95lbs (0.43kg) |
| Packaged Weight | 1.39lbs (0.63kg) |
| Body Color | AV Costar White (Pantone® Cool Gray 1C) |
