Speco - H16HRLN40TB - Grabadora de vídeo digital híbrida Speco H16HRLN40TB de 16 canales y, 40 TB
Part number:
Price:
Product Overview
El grabador de video digital híbrido Speco H16HRLN40TB de 16 canales está diseñado para ofrecer versatilidad y un alto rendimiento de grabación. Con una resolución de hasta 5 MP en todos los canales y 4K en 8 canales, este DVR es ideal para necesidades integrales de vigilancia. Incorpora tecnología avanzada de compresión H.265 para optimizar el almacenamiento.
Key Configuration
Model: H16HRLN40TB | Admite hasta 5 MP en todos los canales y 4K en 8 canales | 2 puertos SATA para hasta 40 TB de almacenamiento | 1 puerto eSATA para 8 TB de almacenamiento adicional | Salida HDMI 4K y salida de monitor VGA
Key Features
- • Compresión H.265: almacene hasta 2 veces más que H.264.
- • Detección avanzada: capacidades de detección de cruce de objetos y líneas.
- • Funcionalidad de búsqueda inteligente.
- • Audio bidireccional: comunicación de audio incorporada.
- • Exportación de vídeo sencilla a través de puertos USB.
Installation Notes
15" x 10.6" x 1.8" (380mm x 268mm x 45mm)
| Specifications | |
| Number Of Channels | 8 Channel; 16 (Specification Sheet (H16HRLN column)) |
| Compression Method | H.265, H.264 |
| Mobile connectivity | Web Browser |
| External Backup | eSATA, USB |
| Harddrive Size | 40TB |
| Features | Free DDNS |
| Default Storage (HDD) | SATAx2, max 40TB per HDD |
| Network | TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP |
| Smart Search | Highlighted color to display camera records in a certain period of time, different colors refer to different record events |
| System | |
| OS | Embeded Linux |
| Video | |
| Analog Input signal | HD-TVI, AHD, CVI, CVBS |
| Analog Inputs | BNC x8, configurable |
| IPC Only Input | 8CH (up to 16-CH)* |
| Network Access & Transfer Bandwidth | 32/96Mbps |
| Network Access Format | 8MP/5MP/4MP/3MP/1080P/960P/720P@ 25/30fps |
| Output | |
| Output | HDMIx1: 4Kx2K/1920x1080/1280x1024 |
| Output | VGAx1: 1920x1080/1280/x1024/1024x768 |
| Output | BNCx1: CVBS (used as the main or spot output) |
| Audio | |
| Input | RCAx8 |
| 2-way Audio | Take up channel one audio input |
| Local Output | RCAx1 |
| Record | |
| Record Stream | Dual stream recording |
| Resolution | 4K/5MP/4MP/1080P/720P/WD1 |
| Frame Rate | Analog: 5MP@ 12fps (PAL/NTSC), 4MP/3MP@12fps/15FPS (PAL/NTSC), Under 4MP@ 25fps/30fps (PAL/NTSC) IP: 8MP and under@ 25/30fps (PAL/NTSC) |
| Bit Rate | 32~78Mbps |
| Mode | Manual, schedule, motion, sensor, intelligence |
| Playback | |
| Simultaneous Playback | Max 8-CH |
| Search Mode | EZ Search, museum search, time search, event search, bookmark search, snapshot search |
| Function | Play, pause, FF, FB, etc. |
| Alarm | |
| Mode | Manual, sensor, motion, exception, intelligence |
| Input | 8-CH local alarm input; Support IPC alarm input |
| Output | 2-CH local alarm input; Support IPC alarm input |
| Linkage | Record, snapshot, preset, e-mail, pop-up window, etc. |
| Network | |
| Interface | RJ45 10M/100M/100Mbps x 1 |
| Protocol | TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, RTSP |
| Web Client | Multiple online users monitoring |
| Mobile Device OS | Speco Blue iOS®, Android™, SecureGuard® Client |
| Other Viewing Platforms | Apple TV® and Amazon Fire TV® |
| Storage | |
| eSATA | eSATAx1 max 8TB |
| Export | |
| Local | USB, USB mobile HDD |
| Network | Yes |
| Interface | |
| USB | USB2.0x2 |
| Remote Control | Yes |
| Dimensions | |
| Power Supply | DC12V/4A |
| Power Consumption | ≤15W(without HDD) |
| Dimensions(WxDxH) | 15" x 10.6" x 1.8" (380mm x 268mm x 45mm) |
Name
Description
Size
Downloads
File
User Manual
6.5mb
File
Quick Installation Guide
0.9mb
File
Specification Sheet
0.8mb
