Speco - HB1 - 4 Megapixel HD-TVI Height Strip Camera (TAA and NDAA Compliant)

Product Overview

The Speco SP-HB1 is a 4MP HD-TVI height strip camera designed for door frames, entrance walls, and doorway jambs. It captures frontal images of people entering or exiting while displaying them against a calibrated height scale for identification and loss prevention. The camera uses coaxial HD-TVI transmission and is TAA and NDAA compliant.

Key Configuration

Model: SP-HB1 | Resolution: 4MP | Camera Type: HD-TVI height strip camera | Connectivity: HD-TVI video over coaxial cable | Application: Entrance monitoring and loss prevention | Compliance: TAA and NDAA

Key Features

• · 4MP HD-TVI video resolution
• · Height strip format for doorway and entrance installations
• · Calibrated height scale supports subject identification
• · Captures frontal images of people passing through entrances
• · Provides full upper-body reference images for investigations
• · HD-TVI transmission over RG59 or RG6 coaxial cable
• · Compatible with HD-TVI DVR systems
• · Suitable for retail, banking, and convenience-store loss prevention
• · TAA compliant
• · NDAA Section 889 Part B compliant

Technical Context

The height strip format places the subject beside a calibrated scale, combining facial and upper-body imagery with an estimated height reference. HD-TVI sends the 4MP analog video over coaxial cabling to a compatible DVR, allowing the camera to operate within traditional coax-based surveillance systems.

Installation Notes

Install the SP-HB1 vertically at a defined height on a door frame, entrance wall, or doorway jamb. Use compatible RG59 or RG6 coaxial cable and connect the camera to an HD-TVI DVR. Position the camera for a clear frontal view of people crossing the entrance.
