Speco - HTINT40T1 - HD-TVI 2MP Intensifier® T Indoor Mini-Board Camera with True WDR, UTC, 2BNC out for TVI & CVBS
Part number:
Price:
Product Overview
3.6mm fixed lens, black housing
Key Configuration
Model: HTINT40T1
Key Features
- • PRESET (Indoor/Outdoor/Lowlight/Hallway/Lobby/Elevator).
- • Full HD resolution over coax (HD-TVI).
- • Supports up to Full HD 1080p @ 30fps.
- • True WDR operation.
- • Superior low-light performance.
Installation Notes
1.65” (W) x 1.86” (H) x 2.2” (Dia.)
| Full Specifications | |
| Housing Color | Black |
| Megapixel | 2MP |
| Camera Specifications | |
| Image Sensor | Sony CMOS Sensor, 2MP |
| Resolution | 1920 x 1080 |
| Minimum Illumination | 0.001 lux |
| Effective Pixels | 1984 (H) x 1105 (V) |
| Total Pixels | 2000 (H) x 1121 (V) |
| TV System | NTSC |
| Scanning System | Progressive |
| S/N Ratio | More than 50dB |
| Frame rate | Max 50P/60P |
| Video Output | 1.0Vp-p / 75 ohms |
| Lens | Manual |
| Electronic Shutter Speed | Auto/Manual (1/30 sec. - 1/30,000 sec.) / Flicker |
| WDR | Color / BW / Auto / Ext |
| Digital WDR | Auto / Auto Ext / AWC - SET / Manual |
| Day/Night | 0 - 20 (level adjustable) |
| White Balance | Brightness |
| 0 - 20 (level adjustable) | AGC |
| Sense-Up | Motion Tracking |
| Motion Detection | On / Off (4 zones) |
| Privacy | On / Off (16 zones) |
| Lens Shading Compensation | On / Off |
| 3DNR | On / Off |
| Defog | 0 - 20 (level adjustable) |
Name
Description
Size
Downloads
File
Specification Sheet
0.9mb
File
User Manual
0.8mb
