Speco - PMM120A - 120W PA Mixer Power Amplifier with 6 Inputs
Part number:
Price:
Product Overview
Speco Technologies’ UL listed Contractor Series amplifiers are designed for long-running, every day use. They can stand on their own to run a smaller installation, or be incorporated into a much larger job. With RMS power ranging from 30W to 120W, microphone and source-mixing ability, telephone paging interface and music-on-hold capability, there’s practically no job where one of these amplifiers wouldn’t be a perfect fit! **Products are in compliance with NDAA Section 889 Part B Guidelines**
Key Configuration
Model: PMM120A
Installation Notes
16.9" (W) × 3.5" (H) × 11.8" (D)
| Full Specifications | |
| Type of Amplifier | Mixer |
| Speaker Specifications | |
| Model | PMM120A |
| RMS Output Power | 120W |
| Max Output Power | 180W |
| AC Power Consumption | 850W |
| Power Supply | AC 120V, 50/60Hz |
| Zones | 1 |
| Speaker Outputs | 4/8/16 Ohms, 70/25V |
| Inputs | 3 × Mic (XLR), 1 × Mic (XLR or Terminal), 3 × Mic/Aux (Terminal or Stereo RCA), 1 × EQ/Mix (RCA) 1 × Tel (Terminal) |
| Frequency Response | 50Hz ~ 15KHz (±3dB) |
| Tone Control | Bass ± 10dB, Treble ± 10dB |
| THD | Less than 1% @ 1KHz |
| Signal/Noise Ratio | Microphone: >60dB TEL: >60dB Line: >70dB |
| Controls | Volume for each source, Master Volume. Vox Sensitivity |
| Telephone | TEL in and MoH Out |
| Indicators | Power, power level |
| Weight | 23.6lbs. |
| Listings | UL, cULm CE, FCC |
Name
Description
Size
Downloads
File
Specification Sheet
0.3mb
File
User Manual
0.4mb
