Speco - WBM6TA - 6.5” Vandal-Resistant Speaker with Built-in 10W amplifier
Part number:
Price:
Product Overview
Speaker is completely enclosed in a sturdy metal enclosure. Design greatly reduces chance of damage to or tampering with speaker. WBM6TA is ideal for surveillance audio applications.
Key Configuration
Model: WBM6TA
Key Features
- • NDAA Compliant.
Installation Notes
7.7" (L) × 7.7" (W) × 3.2" (H)
| Full Specifications | |
| Speaker Color | White |
| Speaker Specifications | |
| RMS Output Power | 20W |
| Max Output Power | 40W |
| Power | 70V/25V Transformer |
| Transformer Settings | 6W, 3W, 1.5W |
| Sensitivity (1W/1M) | 87dB |
| Maximum SPL (Pmax/1M) | 103dB |
| Impedance | 8 Ohms |
| Magnet Material and Weight | Ferrite, 10 oz |
| Frequency Response Range | 110Hz - 20kHz |
| Dispersion | 180° |
| Driver | 6.5" polypropylene cone, rubber edge woofer, .5 PEI dome tweeter |
| Amplifier | 10W |
| Input | 3.5mm |
| Operating Specifications | |
| Dimensions | 7.7" (L) × 7.7" (W) × 3.2" (H) |
| Speaker Weight | 7 lbs |
| Speaker Body Material | Metal |
| Speaker Grille Material | Metal |
