Wi-Tek - WI-AX1800M V2 - Wi-Fi 6 Mesh Router V2

Product Overview

WI-AX1800M V2 is a dual-band Wi-Fi 6 mesh router designed for villas, shopping malls, and other locations requiring scalable wireless coverage. It supports IEEE 802.11a/b/g/n/ac/ax with combined wireless speeds up to 1800Mbps, 2×2 MU-MIMO, automatic network optimization, and routing selection. Mesh networking, self-healing, and Wi-Tek Cloud management support flexible deployment and centralized monitoring.

Key Configuration

Model: WI-AX1800M V2 | Wireless Standard: IEEE 802.11a/b/g/n/ac/ax | Data Rate: 2.4GHz up to 574Mbps, 5GHz up to 1201Mbps | MIMO: 2×2 on 2.4GHz and 5GHz | Antenna: 5dBi on 2.4GHz and 5GHz | Connectivity: 1×10/100/1000Mbps WAN port, 3×10/100/1000Mbps LAN ports | Power: 12V/1A DC | Dimensions: 167 × 144 × 66mm

Key Features

• · Dual-band Wi-Fi 6 connectivity with combined speeds up to 1800Mbps
• · 2.4GHz speeds up to 574Mbps and 5GHz speeds up to 1201Mbps
• · 2×2 MU-MIMO technology supports simultaneous communication with multiple devices
• · One Gigabit WAN port and three Gigabit LAN ports provide wired connectivity
• · Mesh networking supports zero-configuration multi-node deployment and self-healing
• · Automatic channel and transmission-power adjustment optimize wireless performance
• · Supports static IP, DHCP, and PPPoE Internet connection types
• · Guest Wi-Fi, SSID hiding, Wi-Fi isolation, parental control, and IP/MAC binding
• · Supports port forwarding, SD-LAN, OpenVPN, and TCP/UDP flood protection
• · Local web management and remote management through the Wi-Tek Cloud platform

Technical Context

Mesh technology links multiple routers into a coordinated wireless network, allowing coverage to be expanded and supporting automatic switching between wired and wireless backhaul. Self-healing can maintain network availability if a mesh node fails, while MU-MIMO improves efficiency when multiple compatible clients are connected simultaneously.

Installation Notes

The router measures 167 × 144 × 66mm and requires a 12V/1A DC power supply. Connect the upstream service to the WAN port and wired devices to the three LAN ports. Operating temperature is -20°C to 55°C with 5%-95% non-condensing humidity.
