Product Overview
WI-NR3230 is a 5G NR AX3000 Wi-Fi 6 router designed to share high-speed mobile connectivity with wired and wireless devices. It supports 5G SA and NSA modes with download speeds up to 4.67Gbps, dual 2.5Gbps Ethernet ports, Wi-Fi 6 wireless throughput up to 3000Mbps, and backward-compatible 4G operation. A phone jack, SIM/eSIM support, EasyMesh, and TR-069 remote management provide flexible connectivity and administration.
Key Configuration
Model: WI-NR3230 | Cellular Network: 5G NR SA/NSA, LTE, WCDMA | Wi-Fi: IEEE 802.11a/b/g/n/ac/ax, AX3000 | Data Rate: 2.4GHz up to 574Mbps, 5GHz up to 2402Mbps | Connectivity: 1×2.5Gbps LAN RJ45, 1×2.5Gbps WAN RJ45, 1×RJ11 phone jack | Power: 12V/1.5A DC | SIM: eSIM or physical SIM
Key Features
- · 5G NR SA and NSA connectivity with download speeds up to 4.67Gbps
- · Wi-Fi 6 AX3000 wireless performance with combined speeds up to 3000Mbps
- · 2.4GHz speeds up to 574Mbps and 5GHz speeds up to 2402Mbps
- · Two 2.5Gbps Ethernet ports provide high-speed LAN and WAN connectivity
- · Supports eSIM or physical SIM operation with SIM, band, and cell locking
- · Built-in RJ11 phone jack supports voice connectivity
- · Supports 2×2 Wi-Fi MIMO, OFDMA, 1024-QAM, and up to 8 SSIDs per radio
- · Supports IPv4/IPv6, NAT, DHCP, bridge mode, PPPoE, VPN, and EasyMesh 4.0
- · Firewall, DoS protection, port filtering, IP/MAC filtering, URL filtering, and port forwarding
- · Web, Telnet/SSH, TR-069, and command-line management support
Technical Context
Wi-Fi 6 technologies such as OFDMA and 1024-QAM improve wireless efficiency and throughput when multiple devices share the network. The 2.5Gbps Ethernet interfaces allow high-speed wired equipment to use the 5G connection without a Gigabit bottleneck, while bridge mode, VPN, and EasyMesh support flexible network integration.
Installation Notes
The router requires a 12V/1.5A DC power supply and is intended for operation in environments from 0°C to 40°C with 5%-95% non-condensing humidity. Insert a compatible physical SIM or configure eSIM service before establishing the mobile connection.
| General | |
| Model | WI-NR3230 |
| Product Type | 5G NR AX3000 Wi-Fi 6 Router |
| SIM Support | eSIM or physical SIM |
| Hardware | |
| Chipset | T750 + MT7916AN + MT7976DA + 2 × RTL8221B + Le9643 |
| CPU | Quad-core, 2 GHz |
| Memory | 1 GB DDR4 |
| Flash Memory | 1 GB NAND |
| Interfaces | 1 × RJ45 10/100/1000/2500 Mbps LAN port 1 × RJ45 10/100/1000/2500 Mbps WAN port 1 × Reset button 1 × WPS button 1 × Power jack 1 × RJ11 telephone jack |
| Power Supply | 12 V / 1.5 A |
| Wireless | |
| Wireless Standards | IEEE 802.11a/b/g/n/ac/ax |
| Operating Frequency | 2.4 GHz: 2.4–2.4835 GHz 5 GHz: 5.150–5.825 GHz |
| Wireless Data Rate | 2.4 GHz: up to 574 Mbps 5 GHz: up to 2402 Mbps |
| MIMO | 2.4 GHz: 2 × 2 5 GHz: 2 × 2 |
| Antenna | 2.4 GHz: 3 dBi built-in omnidirectional antenna 5 GHz: 3 dBi built-in omnidirectional antenna |
| Transfer Rate | 2.4 GHz HE40: up to 574 Mbps 5 GHz HE40: up to 574 Mbps 5 GHz HE80: up to 1201 Mbps 5 GHz HE160: up to 2402 Mbps |
| Modulation Schemes | OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM DSSS: DBPSK, DQPSK, CCK |
| Wireless Protocols | IEEE 802.11h (DFS) IEEE 802.11e (WMM) IEEE 802.11k/v/r |
| 5G and LTE | |
| 5G/LTE Chipset | MediaTek T750 |
| Cellular Standard | 3GPP Release 15, 5G NR Category 19 |
| 5G NR SA Bands | n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n71/n75/n76/n77/n78 |
| 5G NR NSA Bands | n1/n3/n7/n8/n20/n28/n38/n40/n41/n71/n75/n76/n77/n78 |
| LTE FDD Bands | B1/B3/B5/B7/B8/B20/B28/B32/B71 |
| LTE TDD Bands | B38/B40/B41/B42/B43/B46 (LAA) |
| WCDMA Bands | B1/B5/B8 |
| Cellular Data Rate | 5G SA Sub-6: 4.67 Gbps download, 1.25 Gbps upload 5G NSA Sub-6: 4.47 Gbps download, 730 Mbps upload LTE: 1.6 Gbps download, 211 Mbps upload |
| 5G MIMO | Downlink: 4 × 4; Uplink: 2 × 2 |
| Transmit Power | 23 dBm ±2 dBm |
| Cellular Antenna | 6 × internal directional antennas, 2–6 dBi |
| Network Protocols | |
| Supported Protocols | RFC 0768 UDP RFC 0791 IP RFC 0792 ICMP RFC 0793 TCP RFC 0826 Ethernet ARP RFC 0894 IP over Ethernet RFC 0922 Internet broadcasting RFC 0950 Internet standard subnetting IEEE 802.3 Ethertype IEEE 802.1p RFC 2516 PPPoE RFC 1662 PPP in HDLC-like framing RFC 1332 PPP Internet Protocol Control Protocol RFC 1042 IP datagrams over IEEE 802 networks IPoE over AAL5 |
| Mobile Protocol | 3GPP Release 15 |
| Wireless Features | |
| SSID | Up to 8 SSIDs per radio with separate authentication |
| Wireless Functions | WMM, AutoChannel |
| Mobile Features | |
| Mobile Functions | 5G SA and NSA VoLTE APN and dial settings NAT and bridge mode PIN management SMS management SIM lock, band lock and cell lock AT command web interface |
| Network Features | |
| IP Support | IPv4/IPv6 dual stack, 6RD |
| WAN Connection | IPoE DHCP/static IP, PPPoE dynamic/static IP |
| IPv6 | Stateless and stateful addressing |
| VPN | PPTP, L2TP, GRE, OpenVPN, WireGuard |
| IPTV | IGMP proxy and MLD proxy |
| Network Services | DNS Proxy, DHCP Server, NAT, NAPT and ALG |
| Software Features | |
| QoS | QoS flow control |
| File and Media Services | Samba, DLNA and FTP |
| Firewall and Filtering | DMZ and port forwarding SPI firewall DoS protection Port, IP and MAC filtering URL filtering |
| Routing | DDNS and static routing |
| Time Synchronization | SNTP |
| Diagnostics | Ping and Traceroute |
| System Management | Logs, statistics and automatic scheduled restart |
| Mesh | EasyMesh 4.0 |
| Management | |
| Management Interfaces | Web GUI Telnet and SSH command-line tools TR-069 remote management UPnP |
| Remote Management Standards | TR-181, TR-104, TR-140, TR-143 and TR-157 |
| Environmental | |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 70°C |
| Operating Humidity | 5% to 95%, non-condensing |
| Certifications | |
| Certifications | CE, UL, RoHS |
