Wi-Tek - WI-WR796-BE - 802.11BE Wi-Fi Router

Product Overview

WI-WR796-BE is a Wi-Fi 7 BE9600 tri-band router designed for high-speed home, office, and multi-device networks. It supports IEEE 802.11a/b/g/n/ac/ax/be across the 2.4GHz, 5GHz, and 6GHz bands, with wireless rates up to 1030Mbps, 2880Mbps, and 5760Mbps respectively. Multi-Link Operation, MU-MIMO, OFDMA, 4K-QAM, 320MHz channels, EasyMesh, and a 10Gbps WAN port support high throughput, low latency, and flexible network expansion.

Key Configuration

Model: WI-WR796-BE | Wireless Standard: IEEE 802.11a/b/g/n/ac/ax/be | Data Rates: 2.4GHz up to 1030Mbps, 5GHz up to 2880Mbps, 6GHz up to 5760Mbps | MIMO: 3×3 on 2.4GHz, 2×2 on 5GHz and 6GHz | Connectivity: 1×10/100/1000/2500/5000/10000Mbps WAN, 4×10/100/1000Mbps LAN | Power: 12V/2.5A DC | Channel Width: Up to 320MHz on 6GHz

Key Features

• · Wi-Fi 7 tri-band operation across 2.4GHz, 5GHz, and 6GHz
• · Wireless rates up to 1030Mbps on 2.4GHz, 2880Mbps on 5GHz, and 5760Mbps on 6GHz
• · Multi-Link Operation improves throughput, latency, and connection stability
• · MU-MIMO and OFDMA support simultaneous connections from multiple devices
• · 4K-QAM modulation and up to 320MHz channel width on the 6GHz band
• · 10Gbps WAN Ethernet port supports high-speed Internet access
• · Four Gigabit LAN ports provide wired connectivity for network devices
• · EasyMesh technology supports seamless multi-router wireless coverage
• · Beamforming, band steering, automatic channel selection, and airtime fairness optimize wireless performance
• · Supports IPv4/IPv6, IPTV, VPN, WPA3/SAE security, firewall functions, and TR-069 management

Technical Context

Multi-Link Operation allows compatible clients to use multiple bands or links simultaneously, helping reduce latency and improve connection reliability. OFDMA divides channels into resource units for efficient multi-client communication, while MU-MIMO supports parallel spatial streams. 4K-QAM increases the amount of data carried per symbol, and the 320MHz channel width on 6GHz provides additional capacity for high-throughput applications.

Installation Notes

The router requires a 12V/2.5A DC power supply. Connect the upstream Internet service to the multi-gigabit WAN port and wired devices to the four Gigabit LAN ports. Operating temperature is 0°C to 40°C with 5%-95% typical humidity.
