Cyber Power - CSHT706TCG - 2250 J, 125 V, NEMA 5-15P 45 Degree off-set Plug, 6 ft Cord, Limited Lifetime Warranty
Part number:
CSHT706TCG
Price:

The Home Theater Surge Protector CSHT706TCG provides 2250 joules of surge protection and 7 outlets to safeguard your home theater equipment from damage caused by electrical surges. Data line protection occurs with RJ11 ports for telecommunication devices such as phones, faxes, modems, and DSL lines. Gold-plated RG6 coaxial connectors protect cable/satellite TV receivers and broadband modems.



Features of the CSHT706TCG include automatic shutdown, 7 outlets (4 energy-saving, 1 widely spaced for transformer plugs), a power cord (6 ft.), a right-angle plug with 45° off-set, LED status indicators, impact-resistant casing, metal oxide varistor (MOV) technology, and an EMI/RFI noise filter. This surge suppressor comes with a Limited Lifetime Warranty and a Connected Equipment Guarantee.



Features:

  • Surge Protection: Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
  • Data Line Protection: Prevents power surges that travel through telephone lines from causing damage to electronics.
  • Automatic Shutdown: Protects connected electronics with the integrated circuit breaker which automatically switches off in the event of an overload that exceeds the model’s ability to suppress the signal.
  • EMI/RFI Noise Filter: Maintains clean power for connected equipment by filtering out electromagnetic and radio frequency interference to improve picture and sound quality.
  • Metal Oxide Varistor (MOV) Technology: Allows normal current to pass through the device, while diverting any surges/spikes through the ground circuit, to safeguard connected electronics and the surge suppressor.
  • LED Indicators: Light to indicate the model’s status: Protected and Grounded.
  • Energy-Saving Outlets: Automatically shut off power to attached devices, saving energy, when the master outlet is triggered.
  • Transformer-Spaced Outlet: Accommodates transformer-based plugs without compromising the utility of other outlets.
  • Cord Management System: Keeps cords neat and organized.
  • Impact-Resistant Casing: Ensures maximum durability and prolongs the life of the model.
  • Connected Equipment Guarantee: CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
  • Limited Lifetime Warranty: Covers defects in materials and workmanship in the product under normal use and conditions. See warranty for details.
Input
Circuit Breaker15 A
Cord Length6 ft (1.8 m)
Input Plug TypeNEMA 5-15P
Maximum Input Current15A
Plug StyleRight Angle – 45° Offset
Output
Outlet Type7 – NEMA 5-15R
Outlets – Energy Saving4
Outlets – Total7
Outlets – Widely Spaced1
USB Charge PortNo
USB Charge Port AmperageNone
Surge Protection & Filtering
Attenuation43 dB
Clamping Voltage400V (H-N, H-G, N-G)
Coax Protection RG61 in
1 out
EMI/RFI Filtration150 KHz
100 MHz
Yes
Maximum Surge Current105000 A
Maximum Surge Current H-G30000 A
Maximum Surge Current H-N45000 A
Maximum Surge Current N-G30000 A
Maximum Surge Voltage6000 V
Phone Protection RJ111-In / 2-Out
Response Time<1 Nanosecond
Surge Suppression (Joules)2250 J
Physical
ColorBlack
Cord ManagementYes
Form Factors SupportedHorizontal Mount in Variety of Other Applications
Material of ConstructionPlastic
Safety CoversYes
Dimensions
Physical Dimensions – (WxHxD) (cm)7.9 x 3.99 x 30.96 (cm)
Physical Dimensions – (WxHxD) (in)3.11 x 1.57 x 12.19 (in)
Physical Dimensions – (WxHxD) (mm)79 x 40 x 310 (mm)
Dimensions – Shipping
Shipping – Weight (kg)0.68
Shipping – Weight (lb)1.5
Shipping Dimensions – (WxHxD) (cm)5.49 x 37.47 x 11.43 (cm)
Shipping Dimensions – (WxHxD) (in)2.16 x 14.75 x 4.5 (in)
Shipping Dimensions – (WxHxD) (mm)54.86 x 374.65 x 114.3 (mm)
Certifications
EnvironmentalRoHS Compliant
SafetyUL1363
Warranty
CEG Amount$175000
Connected Equipment GuaranteeLifetime
Product WarrantyLimited Lifetime Warranty
