Break the PoE distance limitation! Wi-Tek provides a robust and cost-effective PoE solution to power up your CCTV, Access point and other IP-based devices which up to 250m away. Most robust features like Extend Mode, PoE Watchdog Function, Port Isolation, provide a lot of value for basic networking needs, creating a versatile and reliable surveillance network to grow your business.
PoE 250m Long Distance to Extend Network:
DIP switch provides Extend Mode. All PoE ports can transmit data and power up to 250 meters. No further hardware or configuration is necessary, easy-to-use and cost-saving. Perfect for surveillance camera deployment in large areas.
Smart PoE Watchdog to Reboot Camera Automatically:
All PoE ports enable PoE watchdog function, which can detect and reboot the offline compliant PoE powered devices.
Port Isolation to Prevent Broadcast Storm:
With VLAN Mode, all PoE ports only can communicate with uplink ports. Avoid data leakage between each port and prevent broadcast storm from disabling network.
Double Uplink to Eliminate the Bandwidth Limit:
Uplink ports superficially resembles any other normal port on a switch or hub. Additionally, connecting the uplink port on one switch to the normal port on another switch cab helps expand the size of the network.
Features:
- 24 1000Mbps RJ45 PoE Ports
- 2 1000Mbps SFP Slots
- Each port supports Supports IEEE 802.3af/at 30W PoE
- PoE power budget can be up to 250W
- CCTV Mode supports 250m long distance and port isolation function
- PoE watchdog detects, reboots unresponsive PoE-powered devices
- Plug and play with no configuration required
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
