H.265 Compression Technology
With this compression technology, the recording capacity is greatly enhanced as well as bandwidth saving for better efficiency and performance than the systems employing other compression formats
Alarm Scenario Customization
“Scenario” is a new feature allowing you to customize a series of actions which will be run automatically after the specified event occurs. There are several scenario templates for you to choose when and what to do after a specific event occurs.
Push Video & Push Status -
Active Event Notification with
EagleEyes App
-Push Video to send instant notifications for an alarm event when an alarm device is connected to the DVR.
-Push Status to send instant notifications for system events, such as video loss or HDD data removal.
IVS
IVS (Intelligent Video System) could be used to set a virtual detection line for people counting, virtual fence, and one-way pass.
It's the advanced usage for motion detection to not only record but also summarize the detection data for further analysis.
Event Pop-up / Preview
All events are listed on the right panel with corresponding event icons for you to quickly recognize the event type. The most current one will flash to catch your attention. Click one event and you’re able to preview the footage with pre-alarm images.
Spot Monitor
In addition to the main display via the main HDMI output, you can assign a secondary display to show live view, call monitor or event monitor.
Hardware
Video Input | One LAN port (up to 16 IP cameras) | ||
|
|
| |
Video Output | HDMI x 2 / VGA x 1 | ||
|
|
| |
Video Output Resolution | HDMI-1: Up to 3840 x 2160 (4K2K) | ||
HDMI-2 & VGA: Up to 1920 x 1080 (Full HD) | |||
|
| ||
|
|
| |
Audio Output | YES (Line out / HDMI) | ||
|
|
| |
Audio Input | YES (Mic in) | ||
|
|
| |
Alarm I/O | 4 in / 1 out | ||
|
|
| |
HDD Storage** | Five 14TB hard disks | ||
|
|
| |
eSATA Port | YES | ||
|
|
| |
RS-485 Port | YES | ||
|
|
| |
USB Ports | USB 3.0 x 1 / USB 2.0 x 2 | ||
|
|
| |
Ethernet | LAN port | 1000Mbps | |
|
| ||
Internet port | 1000Mbps | ||
| |||
|
|
| |
Software |
| ||
Video Compression Format | H.265 | ||
|
| ||
Audio Compression Format | G711 | ||
|
| ||
Local / Remote Display Mode | 16CH | ||
|
| ||
Local / Remote Playback Mode | 16CH | ||
|
| ||
Local Single Channel Playback | YES | ||
|
| ||
Record Stream | Dual | ||
|
| ||
Recording Mode | Manual / Event / Alarm / Schedule | ||
|
| ||
Recording Throughput | Up to 480 IPS @ 2592 x 1944 (5MP), Up to 300Mbps | ||
|
| ||
Pre-alarm Recording | YES | ||
|
| ||
Quick Search | Time / Event | ||
|
| ||
Event Notification | Push Video / Push Status / Video Mail / Message Mail | ||
|
| ||
Security | Multiple user access levels with password | ||
|
|
| |
|
| (1) Internet Explorer on Windows operating system | |
Remote Access | (2) CMS Lite, 32CH CMS software for Windows operating system | ||
|
| (3) EagleEyes on iOS & Android mobile devices | |
|
| ||
Max. Online User | 20 | ||
|
| ||
Multicast | YES | ||
|
| ||
Seamless Recording | YES | ||
|
| ||
Smart Search | YES | ||
|
| ||
EaZy Networking | YES | ||
|
| ||
IVS*** | YES (16CH) | ||
|
| ||
Spot Monitor Setup | Call Monitor / Event Monitor / Live Monitor (HDMI-2 only) | ||
|
| ||
Alarm Scenario Setup | YES | ||
|
| ||
Alarm Pop-up & Preview | YES | ||
