Free P2P Cloud EaZy Networking
Cloud EaZy Networking available to connect this device to Internet automatically in three steps with our free mobile app, EagleEyes.
The “Buddy” feature to share the device access permission to other people.
Device login / out notifications reported.
Alarm Scenario Customization
”Scenario” is a new feature allowing you to customize a series of actions which will be run automatically after the specified event occurs. There are several scenario templates for you to choose when and what to do after a specific event occurs.
Event Pop-up / Preview
All events are listed on the right panel with corresponding event icons for you to quickly recognize the event type. The most current one will flash to catch your attention. Click one event and you’re able to preview the footage with pre-alarm images.
Pentabrid Video Input
32 channels of TVI / CVI / Analog HD / 960H video input + 4 IP channels
Spot Monitor
In addition to the main display via the HDMI output, you can assign a secondary display to show live view, call monitor or event monitor.
Push Video & Push Status - Active Event Notification with EagleEyes App
Push Video to send instant notifications for an alarm event when an alarm device is connected to the DVR
Push Status to send instant notifications for system events, such as video loss or HDD data removal.
8-bay Storage Capacity
To solve the large storage requirement of 1080P recording, this recorder supports up to 8 hard disks to keep high quality video data without overwriting data so quickly. A power-saving mechanism is also adopted to reduce power consumption.
Intelligent Video Analysis
The Smart TVI DVR supports IVS (Intelligent Video System) to set a virtual detection line for people counting, virtual fence, and one-way pass.
Video | |
Video System | NTSC / PAL (auto detection) |
Video Compression Format | H.264 |
Video Signal | IP / TVI / CVI / Analog HD / 960H |
Video Input | 32 quadbrid channels (TVI /CVI / Analog HD / 960H) + 4 IP channels |
Record & Backup | |
Recording Mode | Manual / Timer / Motion / Alarm / Remote |
Pre-alarm Recording | YES |
Playback Channel | 16CH |
Quick Search | Time / Motion / Alarm search mode |
Backup Device | USB 3.0 drive / Network |
Regular Backup | YES (USB hard drive or FTP) |
Audio | |
Audio Input | 16 |
Audio Output (Mono) | 2 |
External I/O | |
RS485 | YES |
Alarm Input | 8 |
Alarm Output | 1 |
Alarm Scenario | YES |
