Bolide - BK-DVR16 - 16-Channel 1080N Pro Hybrid DVR
Part number:
BK-DVR16
Price:
8-Channel 1080N DVR, 80Mbps Throughput, Audio Over Coax, HDMI, 2x USB 2.0, 1x SATA Up to 12TB
Features:
- 16-Channel Hybrid DVR
- Compatible with AHD, TVI, CVI, and Analog Cameras
- 16Mbps IP Channel Throughput
- Bolide QuickConnect Mobile App
- Bolide VMS Software for PC and Mac
| DVR SPECIFICATIONS | |
| Resolution | VGA: 1024x768,1280x720, 1280x1024, 1440x900, 1920x1080 |
| HDMI: 1024x768,1280x720, 1280x1024, 1440x900, 1920x1080, 2560x1440, 3840x2160 | |
| Feature | Single/Quad/S.E.Q/ |
| Record | |
| Resolution | 1080N / 720P / 960H |
| IP: 1080P / 720P | |
| Single IP Channel Preview Up to 2MP 30FPS Multi-Channel, Preview Only Sub-Stream | |
| Speed | Main Stream: |
| 1080N ( 960x1080 ): 30FP | |
| 720P: 30FPS / Channel | |
| IP: PAL: 25FPS / Channel | |
| NTSC: 30FPS / Channel | |
| Sub-Stream: | |
| PAL：704x576: 10FPS/Channel | |
| NTSC：704x480:10FPS/Channel | |
| Video Compression | H.265 / H.264 |
| Video System | NTSC / PAL |
| Operating System | Linux (embedded) |
| Analog video Input/ Output | 16-Channel BNC / HDMI Output |
| IP Video Input | Up to 4-Channels |
| Composite Video Input | Up to 20 Channels ( Analog & IP ) |
| Audio Input/Output | None, Audio Over Coax Only ( Cameras Must Be Set to TVI Mode ) |
| IP-Recording Bandwidth | 16Mbps |
| Max. Output Bandwidth | 80Mbps |
| Recording Mode | Continuous / Manual / Motion Detection / Alarm / Video Analytics |
| Synchronous Playback | Up to 4 Channels |
| Network Type | LAN, DHCP |
| HDD Interface | 1 SATA HDD, up to 12TB |
| USB | 2x USB 2.0 ( Front ) |
| PTZ Control | Control Over Coax, RS-485 |
| Mobile Surveillance | Bolide Quick Connect on iOS / Android |
| Power Supply | DC12V / 2A |
| Dimension | 9.05" x 8.46" x 1.85" |
| Working Temperature | 32°F~+104°F |
| Working Humidity | 10%~90% |
Name
Description
Size
Downloads
File
Datasheet
0.6mb
