TNB-9000 Box Camera Housing, Body/Sun shield : Aluminum, Front & Rear cap : ABS. Wall Mount Arm Included.
Operating Temperature: -50°C ~ +60°C(-58°F ~ +140°F) / 10-100% RH (condensing), Weight: 6.2kg(13.67 lb), Color: White, IP66. Input Voltage 110vac, Thermostat controlled Fan and heater - UL 62368-1 Certified
Features:
- Compatible camera: TNB-9000
- Materials:
- Body/Sun shield : Aluminum
- Front and Rear cap : ABS
- Operating Temperature: -50⁰C ~ +60⁰C(-58⁰F ~ +140⁰F) / 10-100% RH (condensing)
- Weight: 6.2kg(13.67 lb)
- Color: White IP66
- 100-240v AC input, 12v DC output to camera or HPoE passthrough from injector
| Environmental | |
| Operating Temperature / Humidity | -50°C ~ +60°C(-58°F ~ +140°F) / 10-95% RH (condensing) |
| Storage Temperature / Humidity | -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Fan/Heater | Built-in thermostatically controlled, Heating & Cooling Are Independently Thermostat Controlled (FAN ON 45°C (113°F) / FAN OFF 35°C (95°F), HEATER ON 5°C (41°F) / OFF 15°C (59°F)) |
| Certification | IP66, UL 62368-1 FCC, CE, RCM, KC |
| Electrical | |
| Input Voltage | 100-220VAC |
| Power Consumption | Maximum Total 62W - AC FAN (8.8W) : 4.4W*2EA , AC PTC HEATER (7.4W) : 3.7W*2EA, - DC Glass Heater (10W): 10W *1EA, TNB-9000 Camera (30W) : 30W *1EA (TNB-9000 can also be powered via HPOE) |
| Mechanical | |
| Color | White, RAL9003 |
| Material | Body/Sun shield : Aluminum Front & Rear cap : ABS Wall Mount Arm : SUS304 |
| Product dimensions / weight | 300(W)x184(H)x700(D)mm(11.81x7.24x27.56"), 10.5 kg(23 lb) excluding camera / lens |
| Supported products | Camera : TNB-9000 Lens : Canon 24mm f1.4L, Auto-Iris, Canon 35mm f1.4L, Auto-Iris, Canon 50mm f1.4, Auto-Iris, Canon 85mm f1.2L, Auto-Iris, Canon 100mm f2.0, Auto-Iris, Canon 200mm f2.8L, Auto-Iris |
