Computar - TG2Z1816FCS - 1/3" 1.8-3.6mm f1.6 A/I
Part number:
TG2Z1816FCS
Price:
1/3" 1.8-3.6mm f1.6 A/I
| Model No. | TG2Z1816FCS | Effective Lens Aperture | Front | Ø22.0mm | |||
| Focal Length | 1.8mm - 3.6mm | Rear | Ø7.9mm | ||||
| Max. Aperture Ratio | 1:1.6 | Back Focal Length | Tele | 10.5mm | |||
| Max. Image Format | 4.8mm x 3.6mm(Ø6mm) | Wide | 7.0mm | ||||
| Operation Range | Iris | F1.6 - F360C | Flange Back Length | 12.5mm | |||
| Focus | 0.2m - Inf. | Mount | CS-Mount | ||||
| Zoom | 1.8mm - 3.6mm | Filter Size | ---- | ||||
| Control | Iris | DC Auto Iris | Dimensions | Ø37.4mm x 42.6mm x 51mm | |||
| Focus | Manual | Weight | 78g | ||||
| Zoom | Manual | ||||||
| Object Dimension at M.O.D. | 1.8mm | 123.8cm x 56.5cm | |||||
| 3.6mm | 33.2cm x 22.9cm | ||||||
| Angle of View | D | 1/3 type | 173.8° - 99.0° | 1/4 type | 135.8° - 74.4° | ||
| H | 144.2° - 79.4° | 109.5° - 59.6° | |||||
| V | 109.4° - 59.6° | 82.3° - 44.7° | |||||
| Coil | Drive | 190 | |||||
| Control | 855 | ||||||
| Operating Temperature | -20°C - +50°C | ||||||
