The DHI-DB11 WiFi Video Doorbell is a component of the Dahua LincX2PRO camera series. The doorbell offers Passive IR motion detection and transmits video and audio to a mobile phone for remote visual confirmation and communication with visitors. This device is compatible with Dahua NVRs; Dahua X5, X7, and X82 Series HDCVI DVRs, and with the DMSS mobile application. The DHI-DB11 offers high-resolution video ideal for surveillance at homes and small retail or dining establishments.
Features:
- 1/2.7-in. 2 MP Progressive-scan CMOS Sensor
- 2.4 GHz, IEEE802.11b/g/n, 100 m (328 ft) Open Field WiFi
- H.264 Video Compression
- 2 MP at 20 fps Maximum Resolution
- 1.9 mm Fixed Lens
- Built-in Microphone and Speaker for Real-time Communication
- PIR Detection
- Maximum IR LED Length 5 m (16.50 ft)
- Compatible with Alexa®
- Five-year Warranty (for products sold through authorized Dahua Dealers)
| Technical Specifications | |
| Camera | |
| Image Sensor | 1/2.7-in. 2 MP CMOS |
| Effective Pixels | 1920 x 1080, 2 MP |
| Scanning System | Progressive |
| IR Distance | 5.0 m (16.50 ft) |
| Lens | |
| Lens Type | Fixed |
| Focal Length | 1.9 mm |
| Angle of View, Horizontal | 140° |
| Video and Audio | |
| Video Compression | H.264 |
| Resolution | 2 MP at 30 fps |
| PIR | Configurable area and distance: Coverage: up to 120° Distance: up to 5.0 m (16.50 ft) | |
| Input | Built-in Microphone | |
| Output | Built-in Speaker | |
| Audio Compression | G.711 | |
| Network | |
| WiFi | 2.4 GHz WiFi (IEEE802.11b/g/n) |
| Antenna | Internal Dual Antennae, 2 x 2 MIMO |
| Interoperability | CGI |
| Mobile Operating System | IOS, Android |
| Edge Storage | Micro SD Card Slot, maximum 64 GB |
| Compatibility¹ |
|
| Certifications | |
| Safety | EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 (2nd Ed.); Am1:2009 + Am2:2013 |
| Electromagnetic Compatibility (EMC) | CFR 47 FCC Part 15 subpart B , 201 8 EN 55032:2015; EN 55024:2010; EN 50130-4:2011/A1:2014; EN 61000-3-2:2014; EN 61000-3-3:2013 |
| Electrical | |
| Power Supply | 16 VAC to 24 VAC or 12 VDC/24 VDC |
| Power Consumption | < 9 W |
| Environmental | |
| Operating Temperature | –20° C to +50° C (–4° F to 122° F), Less than 95% RH |
| Ingress Protection | IP55 |
| Construction | |
| Casing | Plastic |
| Dimensions | 118.94 mm x 47.0 mm x 29.30 mm (4.68 in. x 1.85 in. x 1.15 in.) |
| Net Weight | 0.14 kg (0.31 lb) |
| Gross Weight | 0.47 kg (1.03 lb) |
