The EDKS-1G is a device designed to interrupt power and streaming of data from up to an IP cameras or other Ethernet connected device The EDKS-1G is placed in-line with the end device's CAT6 Ethernet cable. 12-15vdc is applied or removed to enable or disable the cameras depending on which version EDKS-1G is ordered. A switch can be mounted on the wall of the room along with an external power source to trigger the EDKS-1G. Other equipment that outputs a 12-15vdc 100ma power source can also be used to trigger the EDKS-4.

Includes:

• EDKS-1G IP device kill switch.
• Installation instructions.

Wiring requirements:

2 conductor 22 gauge for connecting 12Vdc trigger voltage.

Features:

• Shielded CAT6 I/O Connectors
• Terminal block for trigger Voltage
• Trigger Voltage LED indicator
• IEEE802.af A and B mode compatible
• Supports 10/100M and 1G data rates
• Makes / breaks pins 1-8 with relays.
• Trigger Voltage Power: 12-15VDC @ 50mA.
• Reverse polarity protected
• Shield / PCB grounding terminal.
• Black plastic ABS housing.
• Dimensions: L5.18 x W2.73 x H2.07
• Weight 0.10lb

Two versions now available:

EDKS-1G-VE applying 12-15vdc enables IP device

EDKS-1G-VD applying 12-15vdc disables IP device
