Extended runtime battery pack for EC3000LCD, tower format, daisy-chain compatible 3-year warranty
Features:
- Multiple battery packs may be daisy-chained together for unlimited runtime
- Tower form factor
- Three-year parts and labor warranty
| SYSTEM SPECIFICATIONS | ||
| Model Number | BP24XL | BP48XL | BP72XL |
| Format | Tower | ||
BATTERY SYSTEM | |||
| Battery Type | Sealed, Non-Spillable, Maintenance Free, Valve Regulated, Lead Acid | ||
| Typical Recharge Time | 24-hours from total discharge | ||
| Typical Battery Life | 3-5 years, depending on discharge cycles and ambient temp | ||
| System Voltage | 24VDC | 48VDC | 72VDC |
| Output Current | 40 Amps (MAX) | ||
| Charge Current | 2.4 Amps (MAX) | ||
| Battery Module | BM0079 | BM0080 | BM0081 |
ENVIRONMENTAL | |||
| Operating Temperature | 0 to 40°C (+32 to +104°F) | ||
| Storage Temperature | -15 to +45°C (+5 to +113°F) | ||
| Operating/Storage Humidity | 10- 90% Non-Condensing | ||
| Operating Elevation | 0 to 3,000m (0 to +10,000 ft) | ||
| Storage Elevation | 0 to 15,000m (0 to +50,000 ft) | ||
PHYSICAL | |||
Size - Net L X W X H (rackmount bracket installed) | 14.1 x 6.1 x 10.2" 356.2x154x258.2mm | 17.4 x 6.8 x 11.4" 440x171x288mm | 23.4 x 6.8 x 11.4" 594.2x171x288mm |
| Weight - Net | 32.6 lbs 14.8 Kgs | 60.6 lbs 27.5 Kgs | 89.3 lbs 40.5 Kgs |
| Size - Shipping L X W X H | 17.8 x 10.3 x 15.1" 450.2x260x383mm | 21.9 x 10.5 x 15.9" 555x266x403mm | 27.9 x 11.2 x 16.3" 708.5x284x412.5mm |
| Weight - Shipping | 35.3 lbs 16.0 Kgs | 63.1 lbs 28.6 Kgs | 92.4 lbs 41.9 Kgs |
REGULATORY COMPLIANCE | |||
| Safety and Approvals | cULus (UL1778 5th Edition & CSA 22.2 no. 107.3-14 / R: 2014), FCC Class A, CE certified, RoHS2 (EU Directive 2011/65/EU & 2015/863/EU) | ||
