Hanwha - SKY-BR420-0 - Wisenet SKY CMVR 420 with 10TB (Rack Form Factor)
Part number:
SKY-BR420-0
Price:
The Wisenet SKY Cloud Managed Video Recorder (CMVR) stores video and acts as a gateway from your premises to the Wisenet SKY Cloud Data Center where your video can also be stored and managed by the Wisenet SKY Cloud VMS. It provides secure video storage & video streaming, intelligent bandwidth management, and monitoring of cameras
Features:
- Supportsup to 30 @ 1MP cameras ~ 25 @ 4MP cameras*
- Supports up to 10 cloud analytics, with supported license
- Intelligent Bandwidth Management with local recording up to 20 days
- Dual gigabit network ports
- HDMI & DisplayPort video outputs for local display
- 1U Rack mount
- Fully cloud managed
- Supportsmotion or continuous recording
- Frontpanel indicator lights
- Supports Wisenet and ONVIF conformant IP cameras
- Completeencryption of video in transit and at rest
STANDARD SUPPORT (Included)
- Free of charge with an active subscription
- No cost replacement with an active subscription
- 24/7 email and web support
- Standard phone support
| Maximum Cameras 1MP | / 30 |
| Maximum Cameras 4MP | / 25 |
| Maximum Cloud Analytics | / 10 |
| Hard Disk Drive | 4TB 15 days for 15 cameras @ 1MP / 10TB 20 days for 30 cameras @ 1MP |
| Network ports | Dual gigabit ethernet RJ-45 |
| Video output | 1x VGA, 1x DVI / 1x VGA, 1x HDMI, 1x DisplayPort |
| Indicator Lights | Power, disk activity |
| Operating System | Embedded Linux |
| USB Ports | x USB 3.0 (front) |
| Included accessories | Power cord, rack mount brackets |
| Rack Mount Brackets | Included |
| Mechanical | Form Factor | Rack mount or shelf/tabletop mount |
| Color / Material | Black / Metal | |
| Dimensions | 1U 16.81" x 9.88" x 1.75" (427mm x 251mm x 45mm) | |
| Weight | 8.95lb (4.06kg) / 9.76lb (4.42kg) | |
| Electrical | Power Supply | Internal, 65 W / 60 W |
| Power Input | ~ 240V AC | |
| Environmental | Operating Temperature | 32°F to 95°F (0°C to 35°C) |
| Operating Humidity | 0% to 70% RH, non-condensing | |
| Certification | FCC, UL, PSE, CE, CCC(S&E), REACH, RoHS, C-Tick, NDAA | |
