The SMT-1933 features a 4:3 aspect ratio wide screen and supports up to 1280 x 1024 resolution, delivering superior image quality DNIe (Digital Natural Image engine). Designed specifically for use in professional security systems it possesses a dynamic contrast ratio of 1000:1, with a 5ms response time. The SMT-1935 is intended to provide security system operators with a high performance durable display solution.
Features:
- Support up to 1,280 x 1,024 resolution
- High contrast ratio 1,000 : 1
- Fast response time 5ms
- Video input : HDMI, VGA, BNC
- Tempered glass screen
Display
| Type | LED |
| Screen Size | 19" |
| Max. Resolution | 1,280 x 1,024 |
| Brightness | 250cd/m2 |
| Contrast Ratio | 1,000 : 1 |
| Aspect Ratio | 4 : 3 |
| Viewing Angle (H/V) | 170° / 160° |
| Display Color | 16.7million |
| Response Time | 5ms |
| Video System | NTSC / PAL |
| Panel Life | 30,000 hours |
| Filter Type | 3D combfilter |
Interface
| Video | Connector | BNC type (2 in / 2 out) |
| VGA | Connector | 1 Analog RGB 15-pin D-sub |
| Input Signal | 0.7Vpp ±5% | |
| Available Format | 720 x 400@70Hz 640 x 480@60Hz/72Hz/75Hz (VGA) 800 x 600@56Hz/60Hz/72Hz/75Hz (SVGA) 1,024 x 768@60Hz/70Hz/75Hz (XGA) 1,152 x 864@75Hz 1,280 x 720@60Hz 1,280 x 960@60Hz 1,280 x 1,024@60Hz/75Hz (SXGA) | |
| HDMI | Connector | 1 HDMI input (Type A connector) |
| Available Format | 640 x 480p@60Hz, 720 x 480i@60Hz 720 x 480p@60Hz, 720 x 576i@50Hz 720 x 576p@50Hz, 1,280 x 720p@50Hz/60Hz | |
| Audio | Connector | 2 RCA type (2 stereo inputs) |
| Output Signal | Speakers : 2 x 1W | |
| Application Support | Remote controller | |
Genreal
| Electrical | Input Voltage | 100 ~ 240V AC (50/60Hz) |
| Power Consumption | Max. 22W | |
| Environmental | Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) |
| Operating Humidity | 20% ~ 90% (Non-condensing) | |
| Mechanical | Dimensions with Stand (WxHxD) | 412.0 x 406.5 x 217.4mm (16.22" x 16" x 8.56") |
| Dimensions without Stand (WxHxD) | 412.0 x 347.0 x 59.4mm (16.22" x 13.66" x 2.34") | |
| Weight | 4.78Kg (10.54 lb) | |
| Protection Glass | Yes | |
| Cabinet Color | Black | |
| Wall Mounts | Optional | |
| VESA Mounts Interface | 100 x 100mm (3.94" x 3.94") |
