Hanwha - WWT-P-3204L - Small form factor Wisenet WAVE Client Workstation for 2 monitor output, Ubuntu Linux 22.04
Part number:
WWT-P-3204L
Price:
The WWT-P-3204 series client workstation is an easily deployable solution that can be used on-site or remotely to access your Wisenet WAVE video recorder running Windows 11 IoT Enterprise LTSC 2024 or Ubuntu Linux 22.04 LTS.
Features:
- Small form factor Wisenet WAVE Client Workstation for 2 monitor output
- Wisenet WAVE pre-installed
- (14th Gen) Intel Core i3
- 8GB RAM
- 256 SSD OS Drive
- Ubuntu Linux 22.04 LTS
- Nvidia Quadro A400 GPU
- Keyboard and mouse included
| SYSTEM | |
| Video Management Software | Wisenet WAVE |
| OS Drive Bays | 1 x 256GB M.2 SSD (internally mounted) |
| Network Interface | 1 x 1GbE RJ-45 Ports |
| Processor | 1 x Intel® Core™ i3 14th Generation |
| Memory | 8GB DDR4 |
| Operating System | Windows 11 IoT Enterprise LTSC 2024 / Ubuntu 22.04 LTS |
| Video Outputs | Nvidia Quadro A400 GPU 4x mDP with 2x HDMI adapters |
| USB Ports | Rear: 2x USB 3.2 Gen 1, 2x USB 2.0; Front: 1x USB 3.2 Gen 1, 1x USB 3.2 Gen 1 Type-C, 2x USB 2.0 |
| Other Ports | 1x 3.5mm universal audio |
| Keyboard & Mouse | Included |
| MECHANICAL / ELECTRICAL / ENVIRONMENTAL | ||
Mechanical | Form Factor | Small Form Factor Workstation |
| Color / Material | Black / Metal & Plastic | |
Dimensions (WxDxH) | 3.65" x 11.53" x 11.42" (92.6mm x 292.8mm x 290mm) | |
| Weight | 11.38 lbs (5.16 kg) | |
| Electrical | Power Supply | 1x 180W 80 Plus Bronze |
| Power Input | 100 ~ 240V AC | |
Power Consumption | Maximum 180W | |
Environmental | Operating Temperature | 50°F ~ 95°F (10°C ~ 35°C) |
Storage Temperature | -40°F ~ 149°F (-40°C ~ 65°C ) | |
| Operating Humidity | 20% to 80% relative humidity (non-condensing) | |
| Certification | UL, cUL, CB, FCC, 80 Plus Bronze | |
