M1 Gold Security and Automation Controls provide the ideal combination of security, energy management, and integrated control solutions. M1 provides rock solid security and life safety with comprehensive detection and state-of-the-art reporting capabilities. It features a fast microprocessor for enhanced speed, capability and security. A onsite voice alerts provide system status information to alleviate user intimidation. Event notifications can be provide via phone call, email, or text message.

M1 Gold is very flexible and scalable with possibilities for expansion, wireless sensors, IP/Cellular reporting, and secure connectivity for remote control.

M1 Gold offers the flexibility to integrate a vast network of industry partners for integration with lighting controls, thermostats, touch screens, and more. This integration combined with our powerful and easy programmable provides an intelligent automation platform for a truly customized solution.


Features:

• Large zone capacity: 16 on-board zones expandable to 208
• Wireless capability: Up to 144 zones
• Two-way Listen-in interface
• RS-232 Serial Port to interface to computers and peripheral devices
• Time/Date stamped 512 event history log
• Menu driven, full text keypad programming - no manual required!
• Voice Announcement of alarms, zone descriptions, status, etc., 500+ Word/phrase Vocabulary, Link up to 6 words/phrases per announcement, 10 custom recordable word/phrases
• 13 On-board Outputs: 1 voice/siren, 1 siren driver, 1 form "C" relay and 10 low current (50mA) outputs
• Can be partitioned into 8 separate areas and account numbers
• User Codes: 199 (4 or 6 digit) with assignable authority levels
• Arm levels: Away, Stay, Stay Instant, Nite, Nite Instant, Vacation
• Flash Memory - Allows field updates to firmware electronically
• Supports 4-wire (any zone) and 2-wire (zone 16) smoke detectors
• Includes fire alarm verification routine• Plug-in terminal blocks make service and pre-wires a snap!
• Hardware "watchdog" and nonvolatile EEPROM memory
• Supervised phone line, alarm output and aux. overcurrent
