Low-profile, High protection
Enspire® Series: standby UPS, LCD display, 900VA/500W, 120VAC input & output, voltage range 95-140VAC, (5) on-battery receptacles, (5) surge-only receptacles, ECO outlet control, 3 min. full load, 11 min. half load, wall mountable, USB comm-port, phone/fax/modem line protection, SentryHD software (via free download), Independent Battery Bypass, Tool-less battery replacement, Hot-swappable battery, coax cable protection, 3-yr Warranty/2-yr. battery warranty, Energy Star certified, RoHS compliant.
The EN750LCD and EN900LCD each have five of the outlets described above for total protection of up to ten connected devices. In addition, all units have outlets which are specifically spaced to support transformer blocks.
Complete Protection for:
- Desktop Computers
- Standalone Servers
- Network Switches, Hubs, and Peripherals
- VoIP Communications
- Telephone Systems
- External Computer Accessories
- Security Cameras and DVRs
Protects Against Spikes, Surges, Brownouts and Blackouts Feature-rich Design
- RJ11/45 Network/Phone/Fax protection
- RoHS 2 compliant
- Transformer-friendly receptacles
- DC Startup capability
- Independent Battery Bypass
- Built-in self-diagnostics testing
- Audio & Visual alarms
Enspire Key Products Features:
Features on 750VA and 900VA Models:
- Easy to Read LCD Display
Real-time updates on system and power status, estimated runtime remaining based on attached load - Green Mode
Lower power consumption mode during off-time - Coax Protection
Protect coaxial cable for AV equipment from damaging spikes and surges - Industry Leading Product Protection
Standard 3-year parts and labor warranty with 2-year non-prorated battery coverage; $50,000 Platinum Protection Plan (US and Canada) - ECO Mode on EN900LCD
| EN900LCD | |
|---|---|
| VA Rating | 900VA |
| Load Capacity (Watts) | 500 |
| Topology | Standby |
| Installation Format(s) | Desktop/Wallmount |
| INPUT | |
|---|---|
| Nominal Voltage Range | 95 - 140VAC |
| Frequency Range | 60HZ ±6Hz |
| Input Surge Protection | Circuit Breaker |
| Surge Joule Rating | 500 |
| Input Plug Type (Cord Length) | NEMA 5-15P (6 ft.) |
| Maximum Input Current | 12 Amps |
| Surge Protection Port(s) | RJ11/45, Coax |
| OUTPUT | |
|---|---|
| Output Voltage Range (AC Mode) | 95 - 140VAC |
| Output Voltage Range (Battery Mode) | 120VAC ±5% until low battery warning |
| Output Waveform (Battery Mode) | Simulated Sine Wave |
| Output Receptacles | "(5) Surge-only / (5) Battery & Surge" |
| BATTERIES | |
|---|---|
| Replacement Module | BM0068 |
| OUTPUT | |
|---|---|
| Tool-less Replacement | Yes |
| Ind. Battery Bypass | Yes |
| DC Startup | Yes |
| Hot-swappable Batteries | Yes |
| Runtime (Full/Half Load) | 3 min. / 11 min. |
| DISPLAY & COMMUNICATIONS | |
|---|---|
| Front Panel Display | LCD |
| Shutdown Software | SentryHDTM - Free via Download |
| Communication Port(s) | USB |
| Comm. Cables Included | Yes |
| OUTPUT | |
|---|---|
| Battery Function Alarms | On Battery, Low Battery, Weak/Bad Battery, Disconnected Battery |
| Alarm Silencer | Yes |
| ENVIRONMENTAL | |
|---|---|
| Operating Temp. Range | +32° to +104°F (0° to 40°C) |
| Operating Humidity Range | 0% to 95% (Non-condensing) |
| Operating Elevation | 10,000 ft. (0 to 3,000m) |
| PHYSICAL | |
|---|---|
| Unit Dimensions (L x W x H) | 3.6" x 7.2" x 12.6" (92 x 183 x 320mm) |
| Shipping Dimensions (L x W x H) | 10.4" x 5.6" x 15.0" (263 x 143 x 382mm) |
| WARRANTY & CERTIFICATIONS | |
|---|---|
| Standard Warranty | 3 Yrs. Electronics / 2 Yrs. Batteries |
| Connected Equipment Guarantee | $50,000 (Continental U.S. and Canada only) |
| Safety Agency Approvals | cTUVus (Conforms to UL1778, CSA 22.2), CE |
| Certifications | FCC Class B, RoHS2 Directive 2011/65/EU |
