PDU 12-outlet 20A Horiz/Vert 208V IEC In/Out

OEPD Series: 208VAC, 16-amp capacity, generic power distribution unit (PDU) w/o Minuteman label, (12) front/(0) back IEC320 C13 outlets, 8.4 foot input cord with NEMA 6-20P plug, 1U/0U horizontal or vertical mounting, UL 62368-1, lifetime warranty included

Minuteman offers high-quality power distribution solutions for IT equipment in network closets and data centers. The OE series features lengthy power cords, versatile configuration options, and a host of premium features, all at an incredible value.

Minuteman’s robust PDU line offers products ranging in capacity from 15 to 30 Amps, in both vertical and horizontal orientations. In addition, select models feature surge suppression and load metering. OEPD power cords are strain-relieved with molded plugs and use heavy-gauged cables. All models have an external ground stud.

Features:

• Longer power cords: Most Minuteman PDU units have 15-ft power cords, eliminating the need for 6-, 8-, or 10-ft alternatives
• More standard outlets: Minuteman PDU units have 6, 8, 10, 14, 18, 20, or 24 outlets. Most of the Minuteman PDUs have additional front outlets for improved access
• Configuration versatility: Minuteman PDU units have a multi-form factor with 1U and 0U configurations allowing for either horizontal or vertical placement. 1U products ship with a stand-off mounting bracket, at no additional cost, that allows for vertical installation on most racks and enclosures
• Locking input plugs (L): Select models (L) feature locking input plugs for added security
• Surge protection (OES): OES models provide surge protection for connected devices
• Load-metering (A): Amp-metered units (A) are available to display connected equipment loads
• High standards: PDUs are listed with higher UL 60950-1 standard. All PDUs are compatible with any data center or network installation UL 60950-1 White Paper
• Cost-effective: More outlets, longer cords, and more features are what make the OEPD Series the best value today. The features are all standard with the series
• Higher reliability: Designed to provide maximum uptime, Minuteman PDUs’ switchless design and on/off LEDs provide greater MTBF (Mean Time Between Failure)
• Protected investment: Minuteman surge-protected (OES) PDUs carry a limited lifetime warranty and a $50,000 Minuteman Platinum Protection Plan (US and Canada only)
