10/100TX Media Converter
The ICS-100 media converters featured at PlanetechUSA.com operate with ease and are dependable units for businesses and enterprises. The unit features simple IP transmission management and user-friendly connection and operation. The ICS-100 media converters connect efficiently to an IP or TCP network and can be managed through a web interface. In addition, the units support the following modes: application mode, alarm connection, serial operation mode, and IP address. The ICS-100 is a dependable converter that saves users time and money.
The ICS-100 media converter connects efficiently to an IP or TCP network and can be managed through a web interface.
- Speed: DB15 to 10/100TX
- Distance: 100m
- Cable: Twisted Pair
- TAA Compliant
Cost-effective Solution for RS-232 / RS-422 / RS-485 to Ethernet Application
PLANET ICS-100 Media Converter / Device Server provides to convert Serial RS-232 / RS-422 / RS-485 communication interface over Fast Ethernet networking. Ethernet signal allows two types of segments to connect easily, efficiently and inexpensively. This converter can be used as a stand-alone unit or as a slide-in module to PLANET Media Converter Chassis (MC-700 / MC-1500/ MC-1500R / MC-1500R48). It is time, saving expense for users and SIs, and there is no need to replace the existing serial equipment and software system.
Remote Manageable
The ICS-100 makes connected serial equipment become the IP-based type. That also makes them able to connect to a TCP / IP networking immediately. Each Web-Smart converter is able to manage Web interface. The powerful Web-Smart Media Converter supports application mode and serial operation mode, connecting alarm, IP address, etc. It helps reduce the amount of valuable time that a network administrator spends detecting and locating network problems; otherwise, it requires visual inspection of cabling and equipment. Multiple connection options for large networking environment are available as well.
| Serial Port | |
| Interface | RS-232 / RS-422 / RS-485 |
| Connector | 3-in-1 DB9 |
| Baud Rate (Data Rate) | 300bps to 921600Kbps |
| Character Bits | 5,6,7,8 |
| Stop Bit | 1, 1.5/2 |
| Flow Control | H/W, None |
| Parity Type | Odd, Even, None, Space, Mark |
| Signals | RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND RS-422: Tx+, Tx-, Rx+, Rx- RS-485 (2-wire): Data+, Data- RS-485 (4-wire): Tx+, Tx-, Rx+, Rx- |
| Fast Ethernet Port | |
| Standard | 10/100Base-TX |
| Connector | RJ-45 |
| Distance | 100m |
| Cable | Twisted-pair |
| Protection | Built-in 1.5KV magnetic isolation |
| Hardware | |
| LED Indicators | System: Power TP Port: Link / Active Serial Port: Serial port mode, RS-232, RS-422 or RS-485 |
| Management | Web Management PLANET Smart Discovery Utility |
| Virtual COM Utility Platform Supports | Windows Base Only: Windows XP Windows Server 2003 Windows 7 Windows Server 2008 Windows 8 (Must install latest version of WinPcap) Windows Server 2012 (Must install latest version of WinPcap) |
| Operation Mode | TCP Server TCP Client UDP Client Virtual COM Telnet Sever Pair Connection-Local(Master) Pair Connection-Pemote(Slave) |
| Dimensions (W x D x H) | 97 x 70 x 26 mm |
| Weight | 200g |
| Power Supply | External Power Adaptor 5V DC / 2A max. |
| Power Consumption | 5.5 watts (max) |
| Mechanical | Metal |
| Environment | Operating Temperature: 0~50 degrees C Storage Temperature: -10~70 degrees C Operating Humidity: 10%~90% RH Storage Humidity: 5%~90% RH |
| Emissions | FCC Class A, CE Certification Class A |
| Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX EIA / TIA RS-232 / 422 / 485 |
| Regulatory Approval | RoHS |
| Compatible Media Converter Chassis | MC-700 / MC-1500/ MC-1500R |
| Note | Reset Button on the rear panel for reset to factory default |
