Outlets can be turned on, turned off, or recycled on demand or at programmed times to address a number of needs including remote rebooting of locked equipment, load shedding, power sequencing, and locking out unauthorized loads. The PDU41001 comes with a three-year limited warranty that covers defects in materials and workmanship in the product under normal use and conditions within three years of the purchase date.
Product Features:
Input | |
Cord Length | 12 ft (3.7 m) |
Derated Input Current | 12:00 AM |
Input Frequency Range | 50 Hz – 60 Hz |
Input Plug Type | NEMA 5-15P |
Maximum Input Current | 15A |
Phase | Single Phase |
Plug Style | Straight |
Output | |
Meter Readout | Power Control Display |
Nominal Output Voltage | 100 – 120 VAC |
Outlet Type | 8 – NEMA 5-15R |
Outlets – # of Banks | 1 |
Outlets – Front | 8 |
Outlets – Rear | 0 |
Outlets – Total | 8 |
Overload Protection | 15A |
Overload Protection (Each Bank) | None |
USB Charge Port | No |
Management & Communications | |
Environmental Sensor | Optional, via RJ45 |
Hardware Connection Port | RJ45, Universal (RJ45), IPv4 TCP/IP UDP SNMPv1 HTTP NTP DNS Telnet DHCP SMTP FTP IPv6 SNMPv3 HTTPs SSH SSL TLS LDAP(S) RADIUS Syslog CLI Windows AD |
LCD | Multifunction LCD |
LED Indicators | Tx/Rx, LINK, Normal/Warning/Critical Status |
Modular Expandability (Cascading) | Yes, via RJ45 |
Outlet switching | Yes |
SNMP / HTTP Remote Monitoring | IPv4, TCP/IP, UDP, SNMPv1, HTTP, NTP, DNS, Telnet, DHCP, SMTP, FTP, IPv6, SNMPv3, HTTPs, SSH, SSL, TLS, LDAP(S), RADIUS, Syslog, CLI, Windows AD |
Upgradeable firmware | Yes |
Physical | |
Adjustable Mounting Brackets | 1 set |
Color | Black |
Cord Retention Tray/Cord Organizers | Yes |
External Site Ground Pin | Yes |
Form Factors Supported | Horizontal or Vertical Wallmount, Horizontal or Vertical Mount in a Variety of Other Surface Types |
Material of Construction | Metal |
Rack Height | 1U |
Style | Horizontal Rackmount, Wallmount |
Dimensions | |
Physical Dimensions – (WxHxD) (cm) | 43.31 x 4.45 x 11.2 (cm) |
Physical Dimensions – (WxHxD) (in) | 17.05 x 1.75 x 4.41 (in) |
Physical Dimensions – (WxHxD) (mm) | 433 x 44 x 112 (mm) |
Physical Weight (kg) | 2.59 |
Physical Weight (lb) | 5.7 |
Dimensions – Shipping | |
Shipping – Weight (kg) | 9.47 |
Shipping – Weight (lb) | 20.88 |
Shipping Dimensions – (WxHxD) (cm) | 25.1 x 6.88 x 49.86 (cm) |
Shipping Dimensions – (WxHxD) (in) | 9.88 x 2.71 x 19.63 (in) |
Shipping Dimensions – (WxHxD) (mm) | 250.95 x 68.83 x 498.6 (mm) |
Environmental | |
Operating Elevation | 0 – 11483 ft (0 – 3500 m) |
Operating Relative Humidity | 0 – 95 % (non-condensing) |
Operating Temperature | 32 – 140 °F (0 – 60 °C) |
Storage Elevation | 0 – 49213 ft (0 – 14999 m) |
Storage Temperature | 5 – 149 °F (-15 – 65 °C) |
Certifications | |
Environmental | RoHS Compliant |
Safety | UL62368 |
Warranty | |
Extended Warranty Option | WEXT5YR-PDU1B |
Product Warranty | 3 Year Limited Warranty |
