TP-Link - RE650 - AC2600 Wi-Fi Range Extender
Part number:
RE650
Price:

Far Reaching Wi-Fi and Powerful Performance

Powerful Quad-Antenna design with Beamforming delivers highly targeted Wi-Fi connections to improve throughput and signal quality for stronger Wi-Fi across your home. The Intelligent Processing Engine balances the demands of your devices to keep their connections fast and uninterrupted, sending Wi-Fi traffic to dedicated processors while the powerful dual-core CPU handles the rest.



4-Stream AC2600 Dual Band Wi-Fi

Using 4-Stream and TurboQAM technology to boost its Wi-Fibandwidth, the RE650 reaches industry leading maximum speeds of up to 800 Mbps on 2.4GHz and 1733 Mbps on 5GHz. This provides the performance necessary to support your most demanding online applications, including 4K streaming and gaming.



More Connections and Faster for Everyone

MU-MIMO technology allows the RE650 to serve up to four devices at once, reducing wait time and greatly increasing Wi-Fi throughput for every device. With MU-MIMO, the RE650 runs up to 4x faster than traditional AC range extender.



Features:

  • Superior Extended Range – Four fixed external antennas extend Wi-Fi coverage*
  • 4-Stream for AC2600 Dual Band Wi-Fi – Simultaneous 800Mbps on 2.4GHz + 1733Mbps on 5GHz
  • 4×4 MU-MIMO** – Simultaneously transfers data to multiple devices for 4x faster performance
  • Beamforming Technology – Send targeted Wi-Fi signal to individual devices for stronger connections
  • Gigabit Ethernet Port – Provide faster wired connections to smart TVs, computers and gaming consoles
  • Intelligent Signal Light – Helps to determine the best location for optimal Wi-Fi coverage by indicating the signal strength in the current placement
  • AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
  • TP-LINK Tether App – Easily access and manage your network using any iOS or Android mobile device
  • Ultimate Compatibility – Extend the range of any Wi-Fi router or wireless access point***
WIRELESS
Working ModesRange Extender/Access Point

HARDWARE FEATURES

Plug TypeUS
Standards and ProtocolsIEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Interface1x 10/100/1000M Ethernet Port (RJ45)
Ports1 Gigabit Ethernet Port
ButtonWPS Button, Reset Button, LED Button, Power Button
Input Power100-240V~50/60Hz
Power Consumption12W(max power consumption)
Dimensions ( W x D x H )6.4x 3.4 x 1.6 in. (163 x 86 x 40mm)
Antenna4x external

WIRELESS FEATURES

Wireless StandardsIEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Frequency2.4GHz & 5GHz(11ac)
Signal Rate

5GHz:Up to 1733Mbps

2.4GHz:Up to 800Mpbs

Reception Sensitivity

5GHz:

11a 6Mbps:-96dBm@10% PER

11a 54Mbps: -78dBm@10% PER

11ac HT20 mcs8: -69dBm@10% PER

11ac HT40 mcs9: -66dBm@10% PER

11ac HT80 mcs9: -63dBm@10% PER

2.4GHz

11g 54M: -79dBm@10% PER

11n HT20 mcs7: -77dBm@10% PER

11n HT40 mcs7: -74dBm@10% PER

Wireless ModesRange Extender/Access Point
Wireless Functions

Wireless Statistic

Concurrent Mode Boost Both 2.4G/5G WiFi Band

High Speed Mode for great speed for HD Gaming and video

Access Control

LED Control

Domain Login Function

Wireless Security64/128-bit WEP WPA-PSK / WPA2-PSK
Transmission Power

<20dBm(2.4GHz)

<23dBm(5GHz)

OTHERS

CertificationFCC, RoHS
Package Contents

AC2600 Wi-Fi Range Extender RE650

Quick Installation Guide

Box Dimensions (W X D X H)7.9 x 4.9 x 3.8in. (202x 125 x 97mm)
System RequirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
Environment

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
