Cyber Power - BP240VL3U01 - UPS SYSTEMS Extended Battery Modules for Smart App Online 6-10KVA
Part number:
BP240VL3U01
Price:

The CyberPower BP240VL3U01 rack/tower convertible Extended Battery Module (EBM) extends UPS runtimes during power outages. Designed for select Smart App Online UPS systems, this EBM takes 3U of rack space and can be installed in a rack or tower configuration to match the UPS form factor. It also has a built-in battery charger, providing Fast Charge Technology to quickly restore the backup power supply from 0-90% in four hours. Up to ten EBMs can be connected in a daisy-chain to the UPS. The BP240VL3U01 typically has a UPS charging time of four hours regardless of whether one or ten EBMs are installed when Fast Charge is connected. The BP240VL3U01 is compatible with OL6KRT, OL6KRTF, OL8KRT, OL8KRTF, OL10KRT, OL10KRTF, and OL10KRTHW. With a three-year warranty, you can trust CyberPower’s commitment to the quality of the BP240VL3U01.



Features:
  • Extended Battery Module
    Extends runtime and restores full backup power quickly with Fast Charge Technology.
  • Hot-Swappable Batteries
    Can be replaced without powering down vital equipment.
  • Fast Charge Technology
    Uses a built-in battery charger in each EBM for quick charging, regardless of the number of EBMs attached to a UPS.
  • Smart Battery Management
    Uses the UPS three-cycle charging mode that improves battery life and reduces generated heat.
  • Plug-and-Play DC Connectors
    Allows for daisy-chaining additional EBMs to a UPS system.
  • Resettable AC Fast Charge Circuit Breaker
    Resets the EBM swiftly in case of an overload.
  • Rack/Tower Configuration
    Allows for horizontal rackmount or vertical tower installation.
  • Three-Year Warranty
    CyberPower will replace a defective EBM (including batteries) within three years of the purchase date. See warranty for details.
GENERAL
Voltage240V
Amperage30A
BATTERY
Battery TypeSealed Lead-Acid
Battery Size12V/7.2AH
Hot-SwappableYes
Replacement BatteryRB1270X10
BATTERY CONT.
Battery Quantity20
User ReplaceableYes
Typical Recharge Time4 Hours
Built-in ChargerYes
Expansion Ready (Daisy-Chain)Yes - Power plugs for Module and Charger
PHYSICAL
Rack Size3U
Mounting HardwareIncluded
Enclosure ConstructionSteel
Dimensions (WxHxD) (in.)17.05 x 5.2 x 26
Dimensions (WxHxD) (mm.)433 x 132 x 660
Weight (lbs.)167.2
Weight (kg.)76
Shipping Dimensions (WxHxD) (in.)23.62 x 14.76 x 35.43
Shipping Dimensions (WxHxD) (mm.)600 x 375 x 900
Shipping Weight (lbs.)204.6
Shipping Weight (kg.)92.8
ENVIRONMENTAL
Operating Temperature32°F to 104°F / 0°C to 40°C
Operating Relative Humidity0% - 90% non-condensing
Operating Elevation0-10000 feet (0-3000 meters)
Storage Temperature5°F to 113°F / -15°C to 45°C
Storage Relative Humidity0% - 95% non-condensing
Storage Elevation0-50000 feet (0-15000 meters)
CERTIFICATIONS
SafetyUL1778, CSA C22.2 NO.107.3-05,
FCC DOC Class A
EnvironmentalRoHS Compliant
WARRANTY
Product Warranty3 Years Limited
