Cyber Power - PR1000LCDRT1U - UPS SYSTEMS Smart App 1000VA/800W, Pure Sine Wave, 1U, NEMA 5-15P, 10 ft cord
Part number:
PR1000LCDRT1U
Price:

A rack/tower convertible UPS with line interactive topology, the CyberPower Smart App Sinewave PR1000LCDRT1U provides battery backup, power protection (using sine wave output), and surge protection for corporate servers, department servers, storage appliances, network devices, and telecom installations requiring Active PFC power source compatibility. The PR1000LCDRT1U uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The PR1000LCDRT1U comes with a three-year warranty and a $400,000 Connected Equipment Guarantee.



Features:

  • Battery Backup: Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
  • Surge Protection: Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
  • Line Interactive Topology: Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
  • Automatic Voltage Regulation (AVR): Provides clean, consistent AC power by automatically increasing (boosting) low voltage without using battery power when incoming utility power experiences minor fluctuations.
  • Sine Wave Output: Provides power protection to ENERGY STAR 6.0 systems with Active PFC power supplies.
  • EMI/RFI Noise Filter: Maintains clean power for connected equipment by filtering out electromagnetic and radio frequency interference to improve picture and sound quality.
  • GreenPower UPS™ Bypass Design: Is a patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
  • Multifunction LCD Panel: Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
  • Rack/Tower Versatility: Allows for horizontal rack or vertical tower installation.
  • Tamper-Proof Power Button: Minimizes the chance the UPS can be accidentally turned off.
  • Audible Alarms: Identify when the model is running on battery power if it is overloaded, or when the battery is low.
  • Resettable Circuit Breaker: Interrupts an electric current in a circuit when the current becomes too high.
  • PowerPanel Business Edition Software: Provides IT professionals with tools for monitoring and managing the UPS and backup power. This software offers remote management functionality.
  • Three-Year Warranty: CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
  • Connected Equipment Guarantee: CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
GENERAL
UPS TopologyLine Interactive
Energy SavingGreenPower UPS™ Bypass Technology
Active PFC CompatibleYes
INPUT
VoltageNominal 120V VAC
Frequency Range57 – 63 Hz
Input Voltage Range80 – 150 VAC
Plug TypeNEMA 5-15P
Plug StyleRight Angle, 45° Offset Right
Cord Length10 ft
OUTPUT
VA1,000 VA
Watts800 W
Automatic Voltage RegulationBoost 1 +30%
Boost 2 +14%
Buck -12%
On Battery Voltage120 VAC ± 5%
On Battery Frequency60 Hz ± 1%
On Battery WaveformSine Wave
Outlet TypeNEMA 5-15R
Outlets - Total7
Outlets - Critical Load3
Outlets - Battery & Surge Protected6
Outlets - Surge-Only Protected1
Rated Power Factor0.8
Overload ProtectionInternal Circuitry Limiting Circuit Breaker
Transfer Time10ms
BATTERY
Runtime at Half Load13 minutes
Runtime at Full Load3.5 minutes
Battery TypeSealed Lead-Acid
Battery Size6V/9Ah
Hot-SwappableYes
Battery Quantity4
User ReplaceableYes
Typical Recharge TimeLess than 6 hours (90% charged)
Replacement BatteryRB0690X4B
SURGE PROTECTION & FILTERING
Surge Suppression1,030 Joules
EMI/RFI FiltrationYes
MANAGEMENT & COMMUNICATIONS
Multifunction LCD PanelDisplays: Current/Load Level, Runtime, Battery Level, Battery In Use, Input Voltage, Output Voltage, Overload, Silent Mode, Normal Mode
HID Compliant USB PortYes
Serial PortYes
EPO PortYes
LED IndicatorsPower On, Wiring Fault
Audible AlarmsOn Battery, Low Battery, Overload
SoftwarePowerPanel® Business Edition
SNMP / HTTP Remote MonitoringYes, with optional RMCARD202, RMCARD203 or RMCARD205
PHYSICAL
Rack Size1U
Form FactorRack
Dimensions (WxHxD) (in.)17.25 x 1.75 x 19.5
Weight (lbs.)35.9
ENVIRONMENTAL
Operating Temperature32 – 104 °F (0 – 40 °C)
Operating Humidity0 – 95% (non-condensing)
Storage Temperature5 – 113 °F (-15 – 45 °C)
Maximum Operating Elevation10,000 ft (3,000 m)
Maximum Storage Elevation50,000 ft (15,000 m)
AC Mode Thermal Dissipation63 BTU/Hr
CERTIFICATIONS
SafetyUL1778 4th
cUL CSA C22.2 No 107.3-05
FCC/DOC Class A
EnvironmentalRoHS Compliant
WARRANTY
Product Warranty3 Years Limited
Connected Equipment GuaranteeLifetime
CEG Amount$400,000
