Cyber Power - CPS1500AVR - UPS SYSTEMS Smart App LCD, 1500VA/900W Line-Interactive Rackmount UPS 8 Outlets
Part number:
CPS1500AVR
Price:

A rack/tower UPS with line interactive topology, the CyberPower Smart App CPS1500AVR provides battery backup (using simulated sine wave output) and surge protection for department servers, workgroup servers, workstations, network devices, and telecom installations without active PFC power supplies. The CPS1500AVR uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CPS1500AVR comes with a three-year warranty and a $300,000 Connected Equipment Guarantee.



Features:

  • Data Line Protection: Prevents power surges that travel through telephone, coaxial, and Ethernet lines from causing damage to electronics.
  • Surge Protection: Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
  • Line Interactive Topology: Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
  • Automatic Voltage Regulation (AVR): Provides clean, consistent AC power by automatically regulating low voltages and over voltages, within defined tolerances, when incoming utility power has minor fluctuations.
  • Simulated Sine Wave Output: Uses pulse wave modulation to generate a stepped, approximated sine wave to supply cost-effective battery backup power for equipment that does not require sine wave output.
  • Rack/Tower Versatility: Allows for horizontal rack or vertical tower installation.
  • LED Status Lights: Indicate Power On, Wiring Fault.
  • PowerPanel Business Edition Software: Provides IT professionals with tools for monitoring and managing the UPS and backup power. This software offers remote management functionality.
  • Three-Year Warranty: CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
  • Connected Equipment Guarantee: CyberPower will repair or replace properly connected equipment if it is damaged by a power surge.
GENERAL
UPS TopologyLine Interactive
Energy SavingGreenPower UPS™ Bypass
INPUT
VoltageNominal 120V
Input voltage range90Vac - 140Vac
Frequency47-63 Hz
Plug TypeNEMA 5-15P
Plug StyleRight Angle, 45° Offset Right
Cord Length10 ft
OUTPUT
VA1500
Watts900
Automatic Voltage RegulationYes - Single Boost (11.5%)
On Battery Voltage120Vac ± 10%
On Battery Frequency50/60Hz ± 1%
On Battery WaveformSimulated Sine Wave
Outlet TypeNEMA 5-15R
Outlets - Total8
Outlets - Battery & Surge Protected8
Overload ProtectionInternal circuitry limiting / circuit breaker
Transfer Time4 ms
BATTERY
Runtime at Half Load18 min
Runtime at Full Load7 min
Battery Voltage12V
Battery Capacity7Ah
User ReplaceableYes
Hot SwappableYes
Typical Recharge Time8 hours
Replacement BatteryRB1270X4F
Battery Quantity4
PROTECTIONS
Surge Suppression1,840 J
EMI/RFI FilteringYes
RJ11/RJ451-In, 1-Out (Combo 10/100)
Coax Protection1-In, 1-Out
MANAGEMENT & COMMUNICATIONS
LCD InterfaceNo
HID Compliant USB PortYes
Serial PortYes (2x) (Dry Contact)
LED IndicatorsLoad Level, Battery Level,Power On, On line, Using Battery, Raplace Battery, AVR, Mute, Overload, Fault, Wiring Fault
Audible AlarmsOn Battery, Low Battery, Overload, Battery Missing, Fault
Software   (Free Download)PowerPanel Business Edition
SNMP / HTTP Remote MonitoringYes, with optional RMCARD205
PHYSICAL
Form FactorRackmount
Dimensions (WxHxD) (inch)17.25 × 3.5 × 15.75
Weight (lb)50.5
ENVIRONMENTAL
Operating Temperature32 °F to 104 °F / 0 °C to 40 °C
Operating Relative Humidity0% - 90% (non-condensing)
Operating Elevation10,000 ft / 3,000 m
Storage Temperature5°F to 113°F / -15°C to 45 °C
Storage Relative Humidity0% - 95% non condensing
Storage Elevation50,000 ft / 15,000 m
CERTIFICATIONS
SafetyUL1778, cUL 107.1, FCC Cl B
WARRANTY
Product Warranty3 Years Limited
Connected Equipment GuaranteeLifetime
CEG Amount$300,000
