Wi-Tek - WI-AP218AX - Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 574Mbps on 2.4 GHz and 1201Mbps on 5 GHz totals 1775Mbps Wi-Fi speeds
Part number:
WI-AP218AX
Price:

Wi-Tek Wi-Fi 6 wireless ceiling AP series is specially designed for indoor Wi-Fi coverage. Support 802.3 PoE power supply, local power supply 12V DC. The dual network port design is conducive to the expansion of thirdparty devices and meets the needs of more networking scenarios. Compatible with 802.11a/b/g/n/ac/ax Wi-Fi protocol, 802.11ax protocol adopts OFDMA, 1024QAM, MU-MIMO, and other key technologies to support faster speed and more user access. In addition, the AP supports cloud management, and users can quickly deploy, configure, remotely manage and operate network-wide equipment, greatly reducing equipment investment costs. Offers fast wireless roaming and wired connectivity, ideal for use in hotels, retail, offices, and more.



Features:

  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 574Mbps on 2.4 GHz and 1201Mbps on 5 GHz totals 1775Mbps Wi-Fi speeds
  • OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously
  • Atheros chipset 1024MB DDR3, 256MB Flash, 500mW High-Power,access 250users
  • 48V PoE Support,2 x Gigabit Port, not include PoE adapter
  • Support QVLAN+SSID, Portal,AC controller Managed and  Cloud Managed

Technical Specs

Wireless StandardsIEEE 802.11ax/ac wave2/wave1/n/b/g/a
Operating Bands2.4GHz & 5GHz
Antenna2.4Ghz:3dBi, 5GHz: 3dBi
Signal Rate

Up to 574Mbps at 2.4GHz

Up to 1201Mbps at 5GHz

Maximum Transmit Power<23dbm
Interface(2)10/100/1000M Base-T Ethernet ports
Power SupplyDC 12V/2A (Not Included)802.3at PoE Supported
Power Consumption<16W
InstallationWall/Ceiling Mounting
External Buttonsreset button (long press for 8 seconds to restore the factory default co nfiguration)
Dimensions198mm * 198mm * 41mm
EnvironmentOperating Temperature:-20℃~55℃
Storage Temperature: Storage Temperature: -40°C~70 °C(non-condensing)
Humidity:5% ~95% (non-condensing)
Name
Description
Size
Downloads
File
Datasheet
0.5mb
