Wi-Tek - WI-AP518AX - Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3550Mbps Wi-Fi speeds
Part number:
WI-AP518AX
Price:

Wi-Tek outdoor AP supports 802.3at PoE power supply, no external power supply is required. Compatible with 802.11a/b/g/n/ac/ax Wi-Fi protocols, 802.11ax adopts OFDMA, 1024QAM, MU-MIMO, and other key technologies to support faster speed and more user access. Through the cloud management function, users can quickly deploy, configure, remotely manage and operate networkwide devices, which greatly reduces labor costs and time costs during wireless network construction. The AP enclosure is designed with an IP67 rating for outdoor environments and is immune to extreme conditions, is an ideal choice for many outdoor wireless scenarios, especially in rural areas, squares.



Features:

  • Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 1148Mbps on 2.4 GHz and 2402Mbps on 5 GHz totals 3550Mbps Wi-Fi speeds
  • OFDMA and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously
  • Atheros chipset 1024MB DDR3, 256MB Flash, 200mW High-Power,access 500users
  • 48V PoE Support,1 x 2.5Gbps Port, not include PoE adapter
  • IP67 rated, weather and dust sealed,Flexible wall or pole mounting options
  • Support QVLAN+SSID, Portal,AC controller Managed and  Cloud Managed

Technical Specs

Wireless StandardsIEEE 802.11ax/ac wave2/wave1/n/b/g/a
Operating Bands2.4GHz & 5GHz
Antenna

external Type-N antennas

2.4Ghz:3dBi, 5GHz: 3dBi

Signal Rate

Up to 1148Mbps at 2.4GHz

Up to 2402Mbps at 5GHz

Maximum Transmit Power<20dbm
Interface(2)10/100/1000M Base-T Ethernet ports
Power Supply802.3at PoE Supported
Power Consumption<22W
InstallationWall Mounting
External Buttonsreset button (long press for 8 seconds to restore the factory default co nfiguration)
Dimensions295.1mm * 231.1mm * 80mm
EnvironmentOperating Temperature:-20℃~55℃
Storage Temperature: Storage Temperature: -40°C~70 °C(non-condensing)
Humidity:5% ~95% (non-condensing)
Name
Description
Size
Downloads
File
Datasheet
0.5mb
