Wi-Tek - WI-CPE515H-KIT - 5.8G 8KM 300M Wireless CPE for CCTV (Sell in Pair)
Part number:
WI-CPE515H-KIT
Price:

Wireless Transmitter is equivalent to a network cable, transmitting network signals via wireless way. It uses wireless communication technology to transmit network data using air as a medium to carry out long-distance point-to-point or point to multi-point interconnection. Wi-Tek Wireless Transmitter is specialized for rural internet access, long-distance wireless data transmission, wireless coverage extension, and other industrial wireless solutions. It is widely used in various fields of communication.



Features:

  • Adjustable transmission power from 0 to 27dBm
  • Built-in 16dBi 2x2 dual-polarized directional MIMO antenna
  • Support open frequency from 5150-5850MHz
  • Long range wireless transmission up to 8km
  • Wireless a/n/ac speed up to 300Mbps
  • Antenna Angle 60° degree
  • Repeater/Basic Station/CPE/WISP operation modes
  • Centralized Management System–Wi-Tek Cloud Platform
  • 24V Passive PoE Adapter supports up to 100 meter
  • Quick paired mode
ModelWI-CPE515H-KIT
Hardware versionV1
HARDWARE FEATURES
Interface(2)10/100M Base-T LAN Ethernet ports
Signal Rate300 Mbps at 5GHz
Operating Band802.11a/n: 5.150~5.850GHz
Antenna TypeBuilt-in 16dBi Directional Antenna
Power Supply24V Passive PoE Adapter
Power Consumption≤6W
Transmit Power≤27dBm (500mW)
Recommend Distance       8km
Antenna Angle60°
External buttonsreset button (long press for 5 seconds
to restore the factory default configuration)
Protection4kV ESD Protection
2kV Lightning Protection
WaterproofIP65
Dimensions200mm x 200mm x 130.5mm
Package Contents2 x CPE
2x 24V Adapter
2 x Accessory Set
1 x Quick Installation Guide
EnvironmentWorking Temp: -33~ 65°C
Storage Temp: -50 ~80°C
Working Humidity: 5%~95% (non-condensing)
SOFTWARE FEATURES
Operating ModesBase Station / CPE / Repeater / WISP Mode
Wireless SecurityWPA-TKIP / WPA2-AES, WPA/WPA2-Enterprise
Wireless ParameterSelectable Channel Width: 20/40MHz
Automatic Channel Selection
Tx Power Control
System ToolsSpeed Test, Ping, Traceroute
ManagementSupport local management with web
Support remote management with Wi-Tek Cloud platform
Name
Description
Size
Downloads
File
Data Sheet
1.2mb
