Wi-Tek PoE Injectors, WI-POE65-2.5G-30W and WI-POE65-2.5G-60W, provide super-fast LAN connectivity with high-power budget, easy to connect your IP phones, IP cameras and access points without power-socket limited. WI-POE65-2.5G-30W and WI-POE65-2.5G 60W, support PoE+ and PoE++ standards respectively, both ensure interoperability with other standard-based PoE-capable devices.
Higher network speed boosts network performance:
WI-POE65-2.5G-30W and WI-POE65-2.5G-60W are here to meet the higher needs of connection for networking devices such as WiFi 6 AP, surveillance PTZ camera or advancedmThin Clients. WI-POE65-2.5G-30W and WI-POE65-2.5G-60W are equipped with 100/1000/2500Mbps RJ-45 ports providing network speeds of up to 2.5Gbps.
Easy to use with robust protection:
Easy to install, simply connect the injectors to an Ethernet switch and to the IP-based PoE device to provide power and data for the network. The compact and lightweight design is easy to install and facilitates deployment of PoE devices with no power outlet requirement. Both PoE injectors have overload and short circuit protection, which shuts down the power immediately if those issues prevail, leaving no damage to your equipment.
Features:
- 2*2.5GE PoE Injector with 2*RJ45 Port
- Support camera, wireless AP, and IP phone etc.
- All ports support wire speed switch, jumbo frame transmission.
- Support 802.3af/at/bt 60W PoE Out
- Plug and play, self-adaption.
- AC IN 100-220V
| HARDWARE FEATURES | WI-POE65-2.5G-60W |
| Interface | 1 100/1000/2500Mbps RJ45 PoE Port |
| 1 100/1000/2500Mbps Ethernet Port | |
| Network Media | 10BASE-T: Cat3.4.5or more UTP(≤100 m) |
| 100BASE-TX: Cat5e or more UTP(≤100 m) | |
| 1000BASE-TX: Cat5e or more UTP(≤100 m) | |
| PoE Budget | 60W |
| Ethernet Standard | IEEE 802.3u 100BASEX Ethernet |
| IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3bz 2.5GBASE-T | |
| Power Input | AC 100-240 V 50/60 Hz |
| PoE Output | IEEE 802.3af/at/bt |
| PoE Pin | 1/2- 3/6+；4/5+ 7/8- |
| Protection Level | 6kV ESD Contact discharge |
| 6kV Lightning protection | |
| Others | |
| Certification | CE、FCC、RoHS |
| LED Indicators | Power |
| Package Dimension | 250×190×60 mm |
| Product Dimension | 185×92×40mm |
| Gross Weight | 0.7kg |
| Net Weight | 0.45kg |
| Package Content | 1×PoE Injector |
| 1×Power Cord | |
| 1×User Guide | |
| Working Environment | Working Temperature: -20~50°C |
| Storage Temperature: -40~80°C | |
| Working Humidity: 10%~90%，non-condensing | |
| Storage Temperature: 5%~90%，non-condensing | |
