WI-PS210G-O

Hardware Features

Hardware Version

 V2

Interface

6 10/100Mbps RJ45 PoE Ports

2 100/1000Mbps RJ45 PoE Ports

2 100/1000Mbps Uplink Ports

1 100/1000Mbps SFP Slot

PoE Ports

Port 1-6: 802.3af/at

Port 7- 8: 802.3 bt 60W

Network Media

10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m)

100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m)

1000BASE-TX: 6 Category and above UTP(≤150m)

Power Supply

AC 110~240V 50/60HZ

Power Budget

120W

Exchange Capacity

11.2Gbps

Packet Forwarding Rate

8.33Mpps

Mac Address Table

4k

Protection

6kV PoE Surge Protection

10kV AC Surge Protection

Jumbo Frame

10240Bytes

SOFTWARE FEATURES

Advanced Functions

Mac Address Auto-Learning And Auto-Aging

Store and forward

IEEE 802.3x flow control for Full-duplex Mode

Backpressure for Half-duplex Mode

OTHERS

Certification

CE, FCC, RoHS

Package Dimension

340×315×120 mm

Switch Dimension

350×255×90 mm

Gross Weight

1.95kg

Net Weight

1.4kg

Package Contents

1 × PoE Switch

1 × Power cord

1 × Quick Installation Guide

1 × Wall mounting KIT

1 × Pole mounting KIT

6 × Screws

Environment

Working Temperature: -30℃ ~70℃(22℉~158 ℉)

Storage Temperature: -40℃~70 ℃ (-40~158 ℉)

Operating Humidity: 10~90% RH non-condensing

Storage Humidity: 5~90% RH non-condensing
