Wi-Tek - WI-PS310GF - 8GE+2SFP uplink Full Giga 802.3af/at PoE Switch with 8Port PoE
Part number:
WI-PS310GF
Price:
Wi-Tek Full Gigabit Switch Serial is an unmanaged PoE switch. As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to PoE terminal equipment such as wireless AP, VoIP, visual intelligent building intercom through network cable, and meet the network environment that needs high-density PoE power supply. It is suitable for hotel, campus, factory dormitory and small and medium-sized enterprises.
Features:
- 8GE+2SFP Unmanaged 24V-48V Auto-detect PoE Switch
- Wi-Tek Smart PoE Tech support 24-48v PoE output via auto-detect
- Support overcurrent protection/short-circuit protection
- 2SFP fiber port for fiber uplink port up 20KM
- Support 48v 802.3af/at and 24v Passive PoE both
- Internl 150W power,dual PoE voltage output design
- 8xPoE Port output
| HARDWARE FEATURES | WI-PS310GF |
| Interface | 8 1000Mbps RJ45 PoE Ports |
| 2 1000Mbps SFP Slots | |
| Network Media | 10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) |
| 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) | |
| 1000BASE-TX: 6 Category and above UTP(≤150m） | |
| Fan Quantity | Fanless |
| Power Budget | 150W |
| Internal Power Supply | AC 110~240V 50/60HZ |
| DC 48-55V | |
| Standard | 802.3 af/at |
| PoE Ports (RJ45) | Port 1-8 |
| DIP Switch | Default/VLAN/Extend |
| 250m Distance | Port 1-8 |
| Exchange Capacity | 20G |
| Mac Address Table | 4k |
| Packet Forwarding Rate | 14.9Mpps |
| Buffer | 1.5Mb |
| Jumbo Frame | 10240Bytes |
| Protection Level | 6kV Lightning protection |
| 6kV ESD Contact discharge | |
| SOFTWARE FEATURES | |
| Transmission Method | Transmission Method |
| Advanced Functions | Mac Address Auto- Learning and Auto-Aging Store |
| and forward IEEE 802.3x flow control | |
| for Full-duplex Mode Backpressure for Half- duplex Mode | |
| OTHERS | |
| Certifification | CE, FCC, RoHS |
| Package Dimension | 270×256×65 mm |
| Switch Dimension | 210×140×45 mm |
| Gross Weight | 1.56kg |
| Net Weight | 0.9kg |
| Package Contents | 1 × PoE Switch |
| 1 × Power Cord | |
| 1 × Quick Installation Guide | |
| Working Temperature | -10℃～55℃ |
| Storage Temperature | -40℃～70℃ |
| Working Humidity | 10% ~ 90% RH non-condensing |
| Storage Humidity | 5% ~ 90% RH non-condensing |
