Minuteman - BP24V72RTEXL - High Capacity Extended Runtime Battery Pack With Internal Charger
Part number:
BP24V72RTEXL
Price:
High-capacity, extended runtime battery pack with internal charger for ED1000RTXL2U(NC) and ED1000RMT2U(NC), rack/tower, 3-year warranty
Features:
- Compact 3U design for densely populated rack and cabinet installations
- Dense internal battery configurations for 2-3x runtime capability
- Rackmount or tower convertible installations are standard with included hardware
- Four-post rail kits included
- Daisy-chain capability (no maximum limit)
- True hot-swappable internal batteries
- User-replaceable internal batteries
- Front panel battery access
- Fast-recharge technology with internal charger
- Unlimited runtime potential
- Three-year standard warranty (non-prorated)
- Optional extended warranty packages available
- Multiple battery packs can be chained. The battery pack does not contain an independent charger.Product Dimensions (in inches) :
- Length: 26.70
- Width/Depth: 17.30
- Height: 5.20
- Weight: 138.90 lbs.
| BP24V72RTEXL | BP36V48RTEXL | BP48V36RTEXL | |
| EnterprisePlus Models | E750RTXL2U, E1000RTXL2U E1500RTXL(T)2U | ||
| Endeavor Models | ED1000RTXL2U, ED1000RMT2U | - | ED1500RTXL2U, ED2000RTXL2U ED1500RMT2U, ED2000RMT2U |
| Internal Battery Charger | Yes | ||
| Charger Output Current | 5.0 Amps | 4.0 Amps | 3.0 Amps |
| Internal Battery Module | BM0082 | BM0083 | BM0084 |
| DC Voltage | 24VDC | 36VDC | 48VDC |
| VAH Rating | 1728VAH | ||
| Battery Type | Sealed, Non-spillable, Maintenance-free, Valve-regulated Lead Acid | ||
| Hot-swappable | Yes | ||
| Typical Recharge Time | 10 hours to 90% after a full load discharge | ||
| Installation Format | Rackmount and Tower (Standard) | ||
| Rack Height | 3U | ||
| Color | Black | ||
| Operating Temperature | 32° - 104°F (0° - 40°C) | ||
| Operating Humidity | 0 – 95% (non-condensing) | ||
| Operating Elevation | 0 – 10,000 ft. (0 – 3,000m) | ||
Unit Dimensions (HxWxD) (mm) | 5.2” x 17.3” x 26.8” (132 x 440 x 680) | 5.2” x 17.3” x 26.8” (132 x 440 x 680) | 5.2” x 17.3” x 26.8” (132 x 440 x 680) |
| Shipping Dimensions (mm) | 10.7” x 22.0” x 35.8” (272 x 560 x 909) | 10.7” x 22.0” x 35.8” (272 x 560 x 909) | 10.7” x 22.0” x 35.8” (272 x 560 x 909) |
Net Weight (Kg) | 131.2 lbs. (59.5 Kg.) | 130.7 lbs. (59.3 Kg.) | 131.0 lbs. (59.4Kg.) |
| Shipping Weight (Kg) | 142.9 lbs. (64.8 Kg.) | 142.4 lbs. (64.6 Kg.) | 142.6 lbs. (64.7 Kg.) |
| Agency Approvals | FCC Class A | ||
| Green Compliance | RoHS2 (EU Directive 2011/65/EU & 2015/863/EU) | ||
| Warranty | Three-year standard (non-prorated) | ||
| Status Display | None | ||
| Daisy-chain Connection | IEC320-C13 to IEC320 C14 (6-foot power cord included) | ||
| Included Power Cord | 10-foot with NEMA 5-15P | ||
| Nominal Input Voltage | 120 VAC | ||
