Hanwha - SLA-T1080F - 1.6mm Fisheye Lens Module
Part number:
SLA-T1080F
Price:
1.6mm fixed lens module, compatible with the XNB-6001. Featuring straight body style, 2MP @ 60fps, 0.03 Lux, 120dB WDR, 187º horizontal field of view, 8 meters cable (26 foot cable).
Features:
- 1.6mm fixed lens module
- Straight body style
- 2MP resolution
- 0.03 Lux
- 120dB WDR
- FoV: H: 187°
- 8m (26ft) cable
| LENS | |
| Focal Length (Zoom Ratio) | 1.6mm |
| Max. Aperture Ratio | F1.6 |
| Angular Field of View | H : 187° |
| Min. Object Distance | 0.3m (0.98ft) |
| Lens Type | Fixed focal |
| MECHANICAL | |
| Color / Material | Lens: Black / Plastic, Metal Cable : Black |
| Dimension (W x H x D) | Lens: Ø35 x 68.9mm (Ø1.38" x 2.71") Cable : 8m (314.96") |
| Weight | 321g (0.71 lb) |
