Hanwha - SLA-T1080FA - 1.6mm fixed lens module, compatible with PNM-9000QB and XNB-6002, straight body style, 2MP @ 30fps, 0.03 Lux, 187º horizontal field of view, 8 meters cable/ 26 feet cable
Part number:
SLA-T1080FA
Price:
1.6mm fixed lens module, compatible with PNM-9000QB and XNB-6002, straight body style, 2MP @ 30fps, 0.03 Lux, 187º horizontal field of view, 8 meters cable/ 26 feet cable
Features :
- Color: 0.03Lux(F1.6, 1/30sec)
- 1.6mm fixed focal
- Compatible with PNM-9000QB
| Video | |
| Imaging Device | 1/2.8" 2MP CMOS |
| Min. Illumination | Color: 0.03Lux(F1.6, 1/30sec) |
| Lens | |
| Focal Length (Zoom Ratio) | 1.6mm fixed focal |
| Max. Aperture Ratio | F1.6 |
| Angular Field of View | H: 187°, V: 113.9° |
| Mount Type | RJ12 connected with main unit |
| Focus Control | fixed |
| Mechanical | |
| Color / Material | Black / Metal |
| Product dimensions / weight | Ø35xL68.9mm, 430g |
