TRENDnet’s Multi-Gigabit Web Smart Switch series offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of today’s SMB networks. These rack-mountable IPv6-ready managed switches each come with an intuitive web-based interface. Advanced managed switch features include LACP to increase bandwidth between switches by grouping ports together, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making these 2.5G managed switches with 10G SFP+ slots powerful solutions for any SMB network. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with an easy-to-use voice VLAN feature.

These multi-gigabit managed switches come equipped with 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over your existing Cat5e or better cabling. The multi-gig managed switches also each offer two dedicated 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability to an SMB network. The design of the switches lowers energy consumption and eliminates distracting operating noise. TRENDnet’s reliable 2.5G managed switches with 10G SFP+ slots offer cost-effective solutions to increase your network’s throughput.

10G SFP+ Slots

Offers two ultra-fast 10G SFP+ slots for high-speed network connections, providing a cost-effective solution in adding 10G link capability.

2.5G Ports

Equipped with eight 2.5GBASE-T RJ-45 ports that provide multi-gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling

Web Smart Management

Provides an easy-to-use web-based GUI management for reduced switch configuration complexity and offers a combination of SMB management features for easy deployment

2.5G Ports

Equipped with eight 2.5GBASE-T RJ-45 ports that provide higher gigabit speeds capable of up to 2.5Gbps over existing Cat5e or better cabling

10G SFP+ Slots

Offers 10G SFP+ slots for high-speed network connections providing a cost-effective solution in adding 10G link capability

IPv6 Ready

This 2.5G managed switch supports IPv6 configuration and IPv6 neighbor discovery

Traffic Management

A broad range of network configurations are supported by: 802.3ad link aggregation, Asymmetric VLAN, 802.1Q VLAN, Voice VLAN, RSTP, MSTP, Loopback Detection, GVRP, 802.1p Class of Service (CoS), port bandwidth management, and QoS queue scheduling

Troubleshooting

A convenient cable diagnostic test and traffic statistics aid in network troubleshooting

Access Control

The 2.5G managed switches include advanced features, such as ACL, SSL, MAC/port filtering, 802.1X, TACACS+, and RADIUS are compatible with layered access controls

Monitoring

RMON, SNMP, SNMP Trap, and Port Mirroring support administrator monitoring solutions

Web Smart Management

The 2.5G managed switch provides an easy-to-use web-based GUI management for reduced switch configuration complexity, and offers a combination of SMB management features for easy deployment

Housing Design

Sturdy metal housing

Jumbo Frame

Sends larger packets, or Jumbo Frames (up to 10KB) for increased performance

LED Indicators

LED indicators on this 2.5G managed switch conveys port status

Features:

• 8 x 2.5GBASE-T ports
• 2 x 10G SFP+ slots
• Backwards compatible with 100/1000BASE-T devices
• Easy-to-use web-based management interface
• Supports IPv6, LACP, VLAN, QoS, and IGMP Snooping
• Bandwidth control per port
• Private, Multicast, and Voice VLAN support
• 80Gbps switching capacity
• IEEE 802.3bz (2.5G) compliant
• IEEE 802.3ae (SFP+) compliant
• NDAA / TAA compliant (U.S. and Canada only)
• Lifetime Warranty*
