Hanwha - SMT-1030PV - 10" IP public view monitor,1080p (1920x1080), HDMI, VGA, Ethernet, 16:9 aspect ratio, Built-in speaker (2x2 W), VESA mountable (75 x 75mm), black casing, face detection display for visual deterrent, 2MP IP camera built-in, 4.6mm
Part number:
SMT-1030PV
Price:
10″ PoE+ Public View Monitor (Black) With 2 Megapixel Camera
Features:
- 10.1" LED 1080p resolution PVM monitor and camera
- Latency-free viewing
- Inconspicuous integrated camera
- Face Detection display for visual deterrent (Colored bounding box around detected face)
- Wide Dynamic Range (150dB)
- Advanced video analytics, motion detection
- Customizable text overlay with pre-configured "Recording in progress" OSD
- Internally powered Camera
- Micro SD/SDHC/SDXC memory slot (256GB)
- H.265, H.264, MJPEG triple codec, Multiple streaming
- IP video and network manageable
- PoE+ / 12v DC powered
| SMT-1030PV | |
| DISPLAY | |
| Screen Size | 10.1" LED backlight |
| Resolution (HxV) | 1024 x 600 |
| Brightness | 500cd/m² |
| Contrast Ratio | 500:1 |
| Aspect Ratio | 16:9 |
| Viewing Angle (H/V) | 140° / 120° |
| Display Color | 262,000 |
| Response Time | 20ms |
| Video System | NTSC / PAL |
| Panel Life | 50,000 hours |
| Filter Type | 3D Comb Filter / Noise Reduction / DeInterlace |
| Key features | Customizable text overlay and blinking "Recording in progress", Slide show |
| INTERFACE | |
| Display connector | NA |
| Network Connector | 1 RJ-45 10/100BASE-T |
| Reset (For Camera) | Yes |
| Language | English, Spanish, French, German, Italian |
| Memory Slot | Micro SD/SDHC/SDXC (Maximum 256GB) |
| Alarm | In 1/ Out 1 |
| ENVIRONMENTAL | |
| Operating temperature/ humidity | 0°C ~ 50°C (32°F ~ 122°F) Up to 40°C @ ≤90% RH, up to 50°C @ ≤50% RH |
| Storage temperature/ humidity | -20°C ~ 60°C (-4°F ~ 140°F) Up to 40°C @ ≤90% RH, up to 60°C @ ≤35% RH |
| Certification | UL, CE, FCC |
| ELECTRICAL | |
| Input Voltage | IEEE802.3at PoE+, DC 12V (110AC - 12v DC Adapter included) |
| Power Consumption | PoE+ 48V 0.28A 13.44W, DC12V 1A |
| MECHANICAL | |
| Color / Material | Black / Galvanized Steel |
Product dimensions(WHD) / weight | 246.2mm x 180.4mm x 64.8mm (9.69" x 7.1" x 2.55") / 2Kg (4.41lbs) / Shipping 338mm x 276mm x 153mm (13.31" x 10.87" x 6.02") 3Kg (6.61lbs) |
| Bezel Size | Top/Side: 11.7mm Bottom: 43.4mm |
| Vesa Mounts Interface | VESA 75mm x 75mm (M4 x 10mm) |
| CAMERA | |
| Imaging Device | 1/2.8" 2MP CMOS |
| Effective Pixels | 1,945(H) x 1,097(V) 2.13MP pixels |
| Minimum Illumination | Color : 0.06 Lux (1/30sec, F2.5) |
| Focal Length (Zoom Ratio) | 4.6mm |
| Wide Dynamic Range | 150dB |
Video Compression Format | H.265 / H.264 / MJPEG |
| Application Programming Interface | ONVIF Profile S/G, SUNAPI (HTTP API) |
