Wi-Tek - WI-CGS5018 - 10SFP+8GE Cloud L2 Managed Fiber Aggregation Switch
• 24 10/100/1000Mbps RJ45 PoE Ports
• 2 1000Mbps SFP Slots
• 802.3af/at PoE+ output with 400W power budget
• Smart DIP Switch
• Plug and play, zero configuration
• 8 Gigabit ports and 10 Gigabit SFP Slots
• Support cloud management, easy to maintain and manage
• Support IGMP Snooping, Link Aggregation, Loop Prevention
• QoS and IGMP snooping function optimize voice, video applications
• Support Web, CLI(Console Port, Telnet, SSH), SNMP and RMON bring powerful management capabilities
| Hardware | |
|---|---|
| Hardware Version | V1 |
| Interface | 24 1000Mbps RJ45 PoE Ports 2 1000Mbps SFP Slots |
| Network Media | 10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000BASE-TX: 6 Category and above UTP(≤150m) |
| Fan Quantity | 2 Fans |
| Power Budget | 400W |
| Internal Power Supply | AC 110~240V 50/60HZ |
| Standard | 802.3 af/at |
| PoE Ports (RJ45) | Port 1-24 |
| DIP Switch | Default/VLAN/Extend |
| 250m Distance | Port 1-24 |
| Exchange Capacity | 52G |
| Mac Address Table | 8k |
| Packet Forwarding Rate | 38.7Mpps |
| Buffer | 12Mb |
| Jumbo Frame | 10240 Bytes |
| Protection Level | 6kV Lightning protection 6kV ESD Contact discharge |
| Software | |
| Transmission Method | Store-And-Forward |
| Advanced Functions | Mac Address Auto-Learning and Auto-Aging Store and forward IEEE 802.3x flow control for Full-duplex Mode Backpressure for Half-duplex Mode |
| Others | |
| Certification | CE, FCC, RoHS |
| Package Dimension | 510×375×90 mm |
| Switch Dimension | 440×290×45 mm |
| Gross Weight | 4kg |
| Net Weight | 3.45kg |
| Package Contents | 1 × PoE Switch 1 × Power Cord 1 × Quick Installation Guide |
| Working Temperature | -10℃～55℃ |
| Storage temperature | -40℃～70℃ |
| Working Humidity | 10% ~ 90% RH non-condensing |
| Storage Humidity | 5% ~ 90% RH non-condensing |
The Wi-Tek Full Gigabit Switch Serial is an unmanaged PoE switch. As a PoE power supply device, it can automatically detect and recognise equipment that meets the standard, supplying power through the network cable. It can supply power to PoE terminal equipment, such as wireless access points (AP), Voice over Internet Protocol (VoIP) systems and visual intelligent building intercoms, via network cables, and can support network environments that require a high-density PoE power supply. It is ideal for hotels, campuses, factory dormitories, and small to medium-sized enterprises.
All ports support high-speed forwarding and flexible networking to meet the networking needs of various scenarios, such as hotels, campuses, factory dormitories, and small and medium-sized enterprises. It is compatible with IEEE 802.3af/at PoE powered devices and meets the requirements for security monitoring, teleconferencing systems and wireless coverage. It supports CE, FCC and RoHS certifications and features a self-developed power supply and high redundancy design to provide long-term, stable PoE power output. The user-friendly panel shows the device status via the PWR, Link and PoE LED indicators, with no configuration required — it's simple and convenient.
